Electrical Manual
VM16,17,24,25,30 Electronic Orient Spindle
SERVING YOUR METAL CUTTING NEEDS FOR MORE THAN 25 YEARS
E2-05 Term Resistance .273 Ohm
E2-06 Leak Inductance 14. %
E2-07 Saturation Comp1 .37
E2-08 Saturation Comp2 .65
E3-01 Control Method 2
E4-01 Max Frequence 2 60. Hz
E4-02 Max Voltage 2 230. VAC
E4-03 Base Frequence 2 60. Hz
E5-01 Motor Rated FLA2 53. A
E5-02 Mot Rated Slip2 1.6 Hz
E5-03 No-load Current 2 15.2 A
E5-05 Term Resistance2 .138 Ohm
E5-06 Leak Inductance2 17.2 %
OPTION
CONSTANTS
F1-01 FG Constant 1024
F1-02 PG Fdbk Loss Sel 1
F1-03 PG Overspeed Sel 1
F1-04 PG Deviation Sel 3
F1-05 PG Rotation Sel 0
F1-06 PG Output Ratio 1
F1-08 PG Overspd Level 115
F1-11 PG Deviate Time .5
F1-14 PGO Time 2.
F4-03 A0 Ch2 Select 3
INPUTS
H1-01 Terminal 3 Sel 2
H1-02 Terminal 4 Sel 4 N/A
H1-03 Terminal 5 Sel 3 N/A
H1-04 Terminal 6 Sel 7
H1-05 Terminal 7 Sel 6 N/A
H1-06 Terminal 8 Sel 77
OUTPUTS
H2-01 Terminal 9 and10 Sel 1 N/A
H2-02 Terminal 25 Sel 2 N/A
H2-03 Terminal 26 Sel 1
H3-01 Terminal 13 Sel 0
H3-02 Terminal 13 Sel 100. %
H3-05 Terminal 16 Sel 0
H4-01 Terminal 21 Sel 3
RS 232
H5-01 Serial Comm Adr 1F
H5-02 Serial Comm Sel 3
H5-03 Serial Corn Sel 0
H5-04 Serail Fault Sel 3
H5-05 Serial Flt Dtct 1
L1-01 Motor Protect OFF 1
L3-04 StallP Decel Sel 0
L8-05 Ph Loss In Sel 0
L8-07 Ph Loss Out Sel 0
WINDING
CHANGE
MC5 2011
Parameter Name 15/10 HP Unit
6422
27 Rev.9
