Electrical Manual
VM16,17,24,25,30 Electronic Orient Spindle
SERVING YOUR METAL CUTTING NEEDS FOR MORE THAN 25 YEARS
Centurion 6 CNC Connector Signal Listing
Pin 4 - Tool carousel counter clockwise
(jumpered to Y-out 5)
Pin 11 - Tool changer arm out (jumpered to Y-in 5)
Pin 5 - Tool carousel orient roller cylinder
(jumpered to Y-out 7)
Pin 12 - Tool carousel orient prox (jumpered to Y-in 7)
Pin 6 - 20 pocket tool changer door open
(jumpered to Y-out 8)
Pin 13 - No connect
Pin 7 - Key Pin 14 - No connect
Connector COM1 (Card Cage)
Pin 2 - TXD
Pin 3 - RXD
Pin 5 - DC ground
All other pins no connect
Connector COM2 For rigid tapping option
Pin 1 - Channel A + Pin 4 - Channel B - Pin 7 - +5 VDC
Pin 2 - Channel A - Pin 5 - Marker + Pin 8 - DC Ground
Pin 3 - Channel B + Pin 6 - Marker - Pin 9 - No connect
Connector Floppy Disk
Standard IBM personal computer floppy disk drive data port
Connector CRT (Video)
Pin 1 - VGA red signal return Pin 14 - VGA red signal
Pin 2 - VGA green signal return Pin 15 - VGA green signal
Pin 3 - VGA blue signal return Pin 16 - VGA blue signal
Pin 4 - Digital ground Pin 17 - VGA vertical synch.
Pin 5 - VGA synch. Return Pin 18 - VGA horizontal synch.
Pin 6 - No connect Pin 19 - No connect
Pin 7 - No connect Pin 20 - No connect
Pin 8 - Serial I/O TXD Pin 21 - Serial I/O RXD
Pin 9 - Front panel handwheel channel A + Pin 22 - Front panel handwheel channel A -
Pin 10 - Front panel handwheel channel B + Pin 23 - Front panel handwheel channel B -
Pin 11 - Cable shield Pin 24 - Keyboard ATCLK
Pin 12 - DC ground Pin 25 - Keyboard ATDAT
Pin 13 - DC ground
Connectors in the CNC control box
Connector CRT (Monitor Power)
Pin 1 - Monitor power 110 VAC line
Pin 3 - Monitor power 110 VAC return
Pin 14 - Monitor chassis ground
(All other pins are no connect)
Connector FPACC
Pin 1 - Front panel fan +24 VDC Pin 8 - Front panel emergency stop common
Pin 2 - Front panel fan DC ground Pin 9 - Setup switch signal
Pin 3 - Chip pan door open feedhold signal Pin 10 - Setup switch common
Pin 4 - Chip pan door open ground Pin 11 - Chip pan door open 110 VAC
Pin 5 - Tool out switch signal Pin 12 - Chip pan door open 110 return
Pin 6 - Tool out switch common Pin 13 - End-of-cycle lamp signal
Pin 7 - Front panel emergency stop signal Pin 14 - End-of-cycle lamp common
Connector P2
Pin 1 - Front panel handwheel channel A + Pin 6 - Serial I/O RXD
Pin 2 - Front panel handwheel channel A - Pin 7 - Keyboard ATCLK
Pin 3 - Front panel handwheel channel B + Pin 8 - Keyboard ATDAT
Pin 4 - Front panel handwheel channel B - Pin 9 - DC ground
44 Rev.9
