Electrical Manual
VM16,17,24,25,30 Electronic Orient Spindle
SERVING YOUR METAL CUTTING NEEDS FOR MORE THAN 25 YEARS
E2-04 Number of Poles 4 4 4
E2-05 Term Resistance 0.156 0.156 0.156 Ohm
E2-06 Leak Inductance 9.4 9.4 9.4 %
E2-07 Saturation Comp1 0.40 0.40 0.40
E2-08 Saturation Comp2 0.69 0.69 0.69
E3-01 Control Method 3 3 3
E4-01 Max Frequence 2 50.0 50.0 50.0 Hz
E4-02 Max Voltage 2 115.3 115.3 115.3 VAC
E4-03 Base Frequence 2 20.0 20.0 20.0 Hz
E5-01 Motor Rated FLA2 64.7 64.7 64.7 A
E5-02 Mot Rated Slip2 0.86 0.86 0.86 Hz
E5-03 No-load Current 2 23.5 23.5 23.5 A
E5-05 Term Resistance2 0.290 0.290 0.290 Ohm
E5-06 Leak Inductance2 14.2 14.2 14.2 %
OPTION
CONSTANTS
F1-01 FG Constant 1024 1024 1024
F1-02 PG Fdbk Loss Sel 1 1 1
F1-03 PG Overspeed Sel 1 1 1
F1-04 PG Deviation Sel 3 3 3
F1-05 PG Rotation Sel 1 1 1
F1-06 PG Output Ratio 1 1 1
F1-08 PG Overspd Level 150% 150% 150%
F1-11 PG Deviate Time .5 .5 .5
F1-14 PGO Time 2 2 2
F4-03 A0 Ch2 Select 5 5 5
INPUTS
H1-01 Terminal 3 Sel 2 24 6
H1-02 Terminal 4 Sel 8 8 8
H1-03 Terminal 5 Sel 80 80 80
H1-04 Terminal 6 Sel 77 77 77
H1-05 Terminal 7 Sel 82 6 82
H1-06 Terminal 8 Sel 7 7 7
OUTPUTS
H2-01 Terminal 9 and10 Sel 1C 1C 1C
H2-02 Terminal 25 Sel 13 13 13
H2-03 Terminal 26 Sel 1 1 1
H3-01 Terminal 13 Sel 0 0 0
H3-02 Terminal 13 Sel 100% 100% 100%
H3-05 Terminal 16 Sel 0 0 0
H4-01 Terminal 21 Sel 3 3 3
RS 232
H5-01 Serial Comm Adr 1F 1F 1F
H5-02 Serial Comm Sel 3 3 3
H5-03 Serial Corn Sel 0 0 0
H5-04 Serial Fault Sel 3 3 3
H5-05 Serial Flt Dtct 1 1 1
L1-01 Motor Protect OFF 0 0 0
L3-04 Stall P Decel Sel 0 0 0
L8-05 Ph Loss In Sel 0 0 0
L8-07 Ph Loss Out Sel 1 1 1
MC5 2015 MC5 2015 MC5 2015
Parameter Name 30/22 HP 30/22 HP 30/22 HP Unit
6422 5422 6422
33 Rev.9
