Pellerin Milnor Corporation 31
plumber the person(s) or contractor licensed or otherwise accepted by the local jurisdiction to
perform the plumbing work described herein, and qualified to do so.
electrician the person(s) or contractor licensed or otherwise accepted by the local jurisdiction
to perform the electrical work described herein, and qualified to do so.
chemical supplier the person(s) or contractor with detailed knowledge of 1) the machine con-
troller configuration and operation, and 2) the pumped chemical delivery system, if such a
system is to be used.
Notices
BNWUUI04.R03 0000255231 D.2 B.4 A.7 1/2/20 2:19 PM Released
Qualified Personnel Only
BNWUUI04.R03 0000255231 D.2 B.4 A.7 1/2/20 2:19 PM Released
— Do not attempt to connect utilities to the machine unless you are a plumber, electrician, or
chemical supplier, as defined above.
Machine Must Be Anchored
BNWUUI04.R03 0000255231 D.2 B.4 A.7 1/2/20 2:19 PM Released
— Utility connections are to be made only after the machine has been anchored. See
BNWUUI03 “Handling a Washer-extractor from Delivery to Final Location.”
Other Tasks
BNWUUI04.R03 0000255231 D.2 B.4 A.7 1/2/20 2:19 PM Released
— This document and the documents it references address common tasks that the plumber, elec-
trician, and chemical supplier will perform. Other tasks, not explained here, can be needed. Infor-
mation about these tasks is usually provided by the dealer, the Milnor
®
Applications Engineering
department, or the Milnor
®
Service department An example is electrical interfacing with a remote
Mildata
®
data collection system.
Utility Requirements and Related Information
BNWUUI04.R05 0000255583 D.2 B.4 A.12 1/2/20 2:19 PM Released
Type of Information Value or Where to Find
equipment list showing
model and options
purchased
For the dealer, see the order acknowledgement.
plumbing connection fitting
types, sizes, and locations
See the standard and options dimensional drawings for your mod-
el located at the back of the installation manual.
water pressure range
10 – 75 psi (69 – 531 kPa) required
Cv value See the specification sheet for your model available online at:
https://www.milnor.com/specification-sheets/. The Cv value as-
sists the piping designer in determining flow rates and pressures.
steam pressure range
30 – 115 psi (207 – 793 kPa) required, if applicable
compressed air pressure
range
85 – 110 psi (586 – 758 kPa) required, if applicable
specified voltage See the machine nameplate or the order acknowledgement.
