32
Pellerin Milnor Corporation
Type of Information Value or Where to Find
available voltages for this
model
See the specification sheet for your model available online at:
https://www.milnor.com/specification-sheets/.
multi-machine conditions
that can interrupt utility
service to a given machine
See dealer publication B22SL94011 “Sizing and Planning a Laun-
dry” found online at:https://www.milnor.com/wp-content/up-
loads/2016/01/Sizing-and-Planning-a-Laundry_18323.pdf
approved plumbing
materials
Plumbing materials must comply with applicable codes. The Mil-
nor
®
factory makes no recommendations for inlet connection ma-
terials due to the many variables such as water conditions,
materials cost and availability, and ongoing advances in materials
technology. When drains must be piped, as apposed to a simple
air drop to a sump, rubber hose and PVC are often used.
Plumber Precautions
BNWUUI04.R01 0000255070 D.2 B.4 A.9 1/2/20 2:19 PM Released
CAUTION: Machine damage and code violations — can occur as a result of incor-
rect plumbing.
� Confirm the reliability of the piped utilities.
� Maintain connection point diameter.
� Flush fluid lines.
� Do not twist valve bodies.
� Never interchange water valve electrical connections.
� Install any vacuum breaker(s) provided or required.
� Install any water strainer(s) provided or required.
� Install a union and a shutoff valve at each hard piped connection.
� Connect a dry supply injector flush inlet to hot water and regulate it.
Precaution Explanation
Confirm the reliability
of the piped utilities.
Water and any other piped fluids (steam, compressed air) needed by
the machine must be within the specified pressure range and not prone
to frequent interruptions when the machine operates. See : Utility Re-
quirements and Related Information, page 31 .
Maintain connection
point diameter.
The piping between the utility tap and the fitting on the machine must
be as large or larger than the fitting. Drain piping or tubing, if any,
must provide an unrestricted flow to the sump.
Flush fluid lines. Foreign material such as debris in air lines, trapped air in water lines,
and condensate in steam lines can damage machine components.
Do not twist valve
bodies.
Hold a wrench on the valve side of a pipe connection to prevent the
valve from twisting when you tighten the connection.
Installation Procedures
