a formula or operate the machine manually. It is not necessary to do the test when the
machine operates.
3. Operate an emergency stop mechanism (examples - button, kick plate, pull cord). If the
mechanis
m operates correctly, the operator alarm comes on. Did this occur?
Yes—Release the emergency stop mechanism if necessary. For example, if this is an
emergency stop button, turn the button clockwise to unlock it. Push the start button
(
1
). Do the test on a different emergency stop mechanism. Continue until you do the
test on all emergency stop mechanisms on the machine.
No—An electrical component is defective. Shut down the machine. Do not let the
machine operate until you correct the problem.
3.1.6. Maintenance Components—Continuous Batch Washer Group
[Document BIPCUM06]
Figure 20: Drive Coupling Components. These are examples. Your machine can look different.
Flexible Coupling—76039CBW Drive Shaft Coupling—76039 CBW
Coupling Chain—92048 CBW Legend
.
1. Flexible coupling (orange plastic)—This
com
ponent can become worn. Usually, you
can replace the plastic component only.
2.
Fl
exible coupling and metal components—
Usually, the metal components do not not
become worn.
3.
Dri
ve coupling—Examine the coupling
for
lo
ose components.
4.
C
oupling chain—With power remove
d,
rem
ove the safety placard. Make sure that
the chain is not loose. Apply grease.
5.
View with safety placard re
moved. Re
place
the placa
rd.
