00A AD 33 023A 91107C INSTL=COOLDN CWM M4567J/P REFERENCE-COOLDOWN INSTL
00B SA 33 054A 91107B*INLET ASSY=CLDN M4567J/P CWM REFERENCE-COOLDOWN ASSY
00C AD 33 011D 92426# FILL TUBE & DRAIN ASSY 240V REFERENCE-ELECTRIC WATER
00D G33 03800C 84512ZINST CWP MICRO H2O 1 1"BALVLV REFERENCE-AIROP VLV INSTL
00E A33 01200 91221C$ ASSY WATERIN ONE 1" BALVALV REFERENCE-AIROP VLV ASSY
00F AVW33002 92126L ASSY=FLOWMETER 3015/3020MXP REFERENCE-LIQUOR FLOW
001 02 03602 91131C+BKT=SUP TOP CLDN CWM M4567JP 00A
002 27A030A U-BOLT 1/2 PIPE 1/4-20 THD 00A
003 12M035 3/8" SCREW IN CONN. PECO #939 00A
004 02 03606 91107B+BKT=SUP BOT CLDN CWM M4567JP 00A
005 51E507N HOSESTEM NYLON 1/4MPTX1/2 HOSE I.D. 00B
006 27A057 HOSECLAMP, 7/16"-1" CADSCREW #HS-8 00A
007 60E085 07Z H0SE WATER 1/2" DAY 7192-50250* 00A
008 SA 33 008 71254B* FILL HOSE ASSY = CWU 00C
009 02 03723 76303C SPLASHSHIELD=CWU INLET 00C
010 02 03487 APR62B2 FILLPIPE SADDLE+CAD 00C
011 27A034 04Z UBOLT 3.625"BETWN LEGS ZINC PLT 00C
012 02 03475 70093A STRAP=FILL PIPE SUPPORT 00C
013 27A034 04Z UBOLT 3.625"BETWN LEGS ZINC PLT 00C
014 02 03478 87366A HANGER=FILL HOSE 00C
015 27A074 HOSECLAMP 2+1/16-3"CADSCR+1/25 BAND 00C
016 02 03447 91247B FILL TUBE NIPPLE (2X3TOE)GAL 00C
017 27A031A 02Z BOLT 1+1/4PIPE 3/8-16THD ZINC 00E
018 02 10539 71010A SPACER FOR PIPE QUANTITY 4 PER BRACKET
019 27A031B 01Z UBOLT 1" PIPE 5/16-18 ZINC PLAT
020 06 20468 87091B HOSE ADAPTER 1+1/4"H X 1"NPT 00E
021 27A060 HOSECLAMP,1+5/16-2.25"CADSCR HS-28 00E
022 60E096 STEAM HOSE 1.25"ID 2WIREBRAID BY FT 00E
023 51LQ1KH03A NIPPLE PIPE 1+1/2 X 3 TOE GALSTL
024 51A053 HEXPIPBUSH 2X1+1/2 GALV 125# CI
025 A33 10600A 77427M*TEE ASSY-STEAM 3 MOTOMETER
026 60E014A02A 79087N HOSE 1.25IDX2"LG PVC 00C
027 27A052 HOSECLAMP 1.5"DIA SPRINGTYPE #R24HC 00C
028 02 03332C 78361B AIRCHAMBER=PRESSWITH-CWU 00C
029 27A044A HOSECLAMP .687D ROTORCLIP#HC-11ST-R 00C
030 A33 12000J 91466# PRES TUBE "T" ASSY MXJ 00C
031A 02 03725 81482B BALVAL COVER SIDE COVER-AIROP HOT+COLD
031B 02 03726 92281C COVER=BALVAL SIDE 3020 COVER-AIROP W/VACUUM BRK
032 02 03725A 92302B BALVAL COVER TOP
033 51V086C TEE PIPE 1+1/2X1+1/2X1+1/4GALMA 150 00F
How to Read Parts List
Reference Item Numbers
—Items 00A, 00B,
00C, etc., or 00X, 00Y, 00Z, etc., appearing at the top of
some parts lists, are for reference and provide:
1. The part number for the entire assembly depicted in
the drawing or a major sub-assembly thereof, and/or
2. The range of machine models this drawing applies to.
If more than one reference item appears, this usually
means this drawing applies to more than one assembly (and
thus to more than one range of machines).
Component Item Numbers
—For any item on
the drawing (e.g., item ➀), there may be several corre-
sponding items on the parts list (e.g., 001A, 001B, 001C,
etc.) which are similar components on different assemblies.
“How Part Is Used In Assembly” identifies which compo-
nents apply to your machine, by listing either the machine
model, or the reference item number from the top of the
parts list (e.g., 00A, 00B, 00C, etc.), or a particular charac-
teristic (e.g., bronze or stainless steel), or special ordering
information, such as a repair kit number.
BMP920016/93251V (Page 2)
WATER INLET AND LEVEL SWITCH INSTALLATION & MOUNTING HARDWARE
30015, 30020 & 30022 RIGID MOUNT WASHER-EXTRACTORS
