Milnor C Series Service Manual

R
Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the parts list to the illustration.
Item
Part Number
Description
Comments
Used In
Parts List, cont.—Hays Electric Inlet Valves
Parts List—Hays Electric Inlet Valves
BMP700710/96081V
(Sheet 2 of 2)
. ---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
S 96P014 02Z 3/8" VALVE 120V HAYS 2195-0055 T 96P016 10Z 1/2" DUOVAL 120V HAYS3108-6021 U 96P016A24 08Z 1/2" DUOVAL 24V HAYS3108-6421 V 96P016A71 05Z 1/2" DUOVAL 240V HAYS3108-6121 W 96P053 05Z 3/4"VAL 24V HAYS 2110-6421IS X 96P053A37 06Z 3/4"VAL 110V HAYS #2110-6021IS XX 96P053A71 3/4" HAYS VALVE 240V60/50C FACTMADE Y 96P151 09Z 1+1/4" VAL 24V HAYS 2110-6421IS Z 96P151A37 05Z 1+1/4" VAL 110V HAYS2110-6021IS ZZ 96P151A71 1.25" HAYSVALVE 240V60/50C FACTMADE
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------ S 1 96V245 PISTON ASSY HAYS #7735505 T-V 1 96V216 PISTON-TEFLON FOR HAYS STYLE 3108 W-XX 1 96V222 PISTON ASSY HAYS 7730004 FOR 96P053 Y-ZZ 1 96V224B PISTON ASSY HAYS #7643101=96P151 all 1 96V216A PISTON-TEFLON FOR HAYS STYLE 4108 OBSOLETE 4108
DUOVALVE
S-V, 2 96V247 SEATWASHER HAYS #8222301 96P014+16 OBSOLETE 4108
DUOVALVE ALSO
W-XX 2 96V225 SEAT WASHER HAYS #8249801 Y-ZZ 2 96V225A SEAT WASHER HAYS #84048 FOR 96P151 S-V, 3 96V248 SEATWASHER NUT HAYS#82222 96P014+16 OBSOLETE 4108
DUOVALVE ALSO
W-Z 3 96V226 SEAT WASHER NUT HAYS #86030 =96P053 S-V 4 96V246 COUPLING NUT HAYS #76303 96P014+16 W-Z 4 96V254 COUPLING NUT HAYS #76028 = 96P053 S-V,Y-ZZ 5 96V244 PISTON SPRING FOR HAYS STYLE 3108 W-XX 5 96V222A PISTON SPRING HAYS 82488 all 5 96V244A PISTON SPRING HAYS 4108 HAYS #88108 OBSOLETE 4108
DUOVALVE
S-V 6 96V242 BONNET FOR HAYS 3108 HAYS#83021 W-XX 6 96V258 BONNET HAYS #73026 FOR 96P053 Y-Z 6 96V260 BONNET HAYS #83192 FOR 96P151 S onlY 7 96V243 PLUNGER ASSY TEFLON TIP HAYS #74327 T-ZZ 7 96V223 PLUNGER HAYS #7319503 all 7 96V223A PLUNGER ASSY FOR HAYS STYLE 4108 OBSOLETE 4108
DUOVALVE
S-T,X,Z 8 96V211 COIL 120V50/60C FOR HAYS STYLE 3108 U,W,Y,ZZ 8 96V210 COIL 24V50/60C FOR HAYS STYLE 3108 V,XX 8 96V212 COIL 240V50/60C FOR HAYS STYLE 3108 S-V, 9 96V217 TEFLON SPLIT RING 1/2" HAYS#8502901 OBSOLETE 4108
DUOVALVE ALSO
W-XX 9 96V222T TEFLON SPLIT RING HAYS #8503002 Y-ZZ 9 96V224T TEFLON SPLITRING 1 1/4"HAYS#8503102 Y-ZZ onlY 10 96V229 BONNET GASKET HAYS #82224= 96P151 Y-Z onlY 11 96V261 O-RING (SEAL CAP) HAYS#87407=96P151 all 12 96V250 PALNUT HAYS #3069-PC all 13 96V251 SPRING WASHER HAYS #83600 all 14 96V264 BOTTOM PLATE (COIL) HAYS#8223601 all 15 96V262 FERRULE (COIL SLEEVE) HAYS #82239 all 16 96V244PS PLUNGER SPRING FOR HAYS STYLE 4108 OBSOLETE 4108
DUOVALVE ONLY
all 17 96V250A COIL RETAINER HAYS4108 HAYS #82958 (NOT SHOWN)
OBSOLETE 4108 DUOVALVE
BMP700710/96081V (2 of 2)
