00A AD 33 028B 90482@*STM INLET ASSY=N4S 3020 120V REFERENCE 30020M5P/M7P
00B AD 33 028C 90482@*STM INLET ASSY=N4S 3015 120V REFERENCE 30015M4P/M6P
00C AD 33 028D 90482@ STEAM INLET ASSY 3020 240V REFERENCE 30020M5J/M7J
00D AD 33 028E 90482@ STM INLET ASSY= 3015 240V REFERENCE 30015M4J/M6J
00E A33 10500 77427Q* STEAM INJECTOR ASSY C4/C6M 00B,00D(CONTAINS 004-012)
00F A33 10500A 77427Q*STEAM INJECTOR ASSY C5M 00A,00C(CONTAINS 004-012)
00G A33 10600 77427M*TEE ASSY-STEAM 2 MOTOMETER 00A-00D(CONTAINS 015-017)
00H A33 10600A 77427M*TEE ASSY-STEAM 3 MOTOMETER 00A-00D(CONTAINS 015-017)
00J A33 10700A 90482#$STEAM INLET ASSY 120V60C+ 00A,00B
00K A33 10700B 90482# STEAM INLET ASSY 240V50/60 00C,00D
001 W2 03608 92042B* STEAM ELBOW=C4M+C6M ONLY
002 27A075 T-BOLT HOSECLAMP 2.75"-3.06"
003 60E301A10A HOSE= *2.5"ID PE X10"
004 W2 03609 74488B* STEAMPIPE WLMT=3015CWM L=9" 00E,00F
005 51LQ1AG07A NIPPLE PIPE 1 X 7 GALSTL 00E,00F
006 27A500 STEAM HEATER 3/4" BRZ. PENB.#NWH 00E,00F
007 51LQ0PG03A NIPPLE PIPE 3/4 X 3 GALSTL 00E,00F
008 51V108C TEE PIPE 2+1/2X2+1/2X2 GALMAL 150# 00E,00F
009 51A059 HEXPIPBUSH 2+1/2X1 GAL 125#CI 00E,00F
010 51E037 01Z COUP 3/4"F W/1"M NPTONOD 304S 00E,00F
011 51A032 HEXPIPBUSH 3/4X1/2 GAL 150# 00E,00F
012 02 15847C 85426B ADAPTER,CARBSTL2-1/2HOSX2NPT 00E,00F
013 27A075 T-BOLT HOSECLAMP 2.75"-3.06"
014 60E301A10A HOSE= *2.5"ID PE X10"
015A 02 03657 77406A SPECIAL-TEE=2HOLES=STEAM CWM 00G
015B 02 03657A 77406# SPECIAL-TEE=3HOLES=STEAM CWM 00H
016 51LQ2AD02M 05Z 2 X2+5/8" STD TOE NON-STD 00G,00H
017 02 03447 91247B FILL TUBE NIPPLE (2X3TOE)GAL 00G,00H
018 12P11ESB SNAPBUSH 1.25MH X.94 T=1/8SB1250-15 00A-00D
019 12K077 STRAP 1/2"HVYCONDUIT 2HOLE VICTR23S
020 02 14170 89526B SUPPORT=PIPE SUPPLEMNT STEAM
******** END OF PARTS LIST ********
How to Read Parts List
Reference Item Numbers
—Items 00A, 00B,
00C, etc., or 00X, 00Y, 00Z, etc., appearing at the top of
some parts lists, are for reference and provide:
1. The part number for the entire assembly depicted in
the drawing or a major sub-assembly thereof, and/or
2. The range of machine models this drawing applies to.
If more than one reference item appears, this usually
means this drawing applies to more than one assembly (and
thus to more than one range of machines).
Component Item Numbers
—For any item on
the drawing (e.g., item ➀), there may be several corre-
sponding items on the parts list (e.g., 001A, 001B, 001C,
etc.) which are similar components on different assemblies.
“How Part Is Used In Assembly” identifies which compo-
nents apply to your machine, by listing either the machine
model, or the reference item number from the top of the
parts list (e.g., 00A, 00B, 00C, etc.), or a particular charac-
teristic (e.g., bronze or stainless steel), or special ordering
information, such as a repair kit number.
BMP920021/93251V (Page 2)
STEAM INSTALLATION
30015, 30020 & 30022 RIGID MOUNT WASHER-EXTRACTORS
To Next Page
