00A 96P039 01Z 1/2"STEAMVALVE 24V50/60C 150PSI 1/2" VALVE- 24 VOLT
00B 96P039A37 01Z 1/2"STEMVALVE 120V50/60C 150PSI 1/2" VALVE- 120 VOLT
00C 96P039A71 01Z 1/2" STEMVALVE 240V50/60 150PSI 1/2" VALVE- 240 VOLT
00D 96P040E 01Z 3/4"STEAMVALVE 24V50/60C 150PSI 3/4" VALVE- 24 VOLT
00E 96P040A37 01Z 3/4"STEMVALVE 120V50/60C 150PSI 3/4" VALVE- 120 VOLT
001A 96V224S PISTON ASSY. STEAMVALE HAYS#6332-PC 00A,00B,00C
001B 96V224SA PISTON ASSY. STEAMVALE HAYS#7798-PC 00D,00E
002A 96V225S PISTON SEAT WASH HAYS #5553-PC 00A,00B,00C
002B 96V225SA PISTON SEAT WASH HAYS #5567-PC 00D,00E
003A 96V248 SEATWASHERNUT#2222-PC=96P014+96P016 00A,00B,00C
003B 96V226 SEAT WASNUT HAYS#6030=96P053&220 00D,00E
004A 96V246 COUPLING NUT HAYS#6303-P=96P014+016 00A,00B,00C
004B 96V254 COUPLING NUT HAYS#6028-P FOR 96P053 00D,00E
005A 96V244 PISTON SPRING FOR HAYS STYLE 3108 00A,00B,00C
005B 96V222A PISTON SPRING HAYS 2488-PC 00D,00E
006A 96V242 BONNET FOR HAYS STYLE 3108 #3021-PC 00A,00B,00C
006B 96V260 BONNET HAYS#3192-PC FOR 96P151 00D,00E
007 96V223 PLUNGER HAYS #3195-3PC
008A 96P040V24 COIL 1/2"&3/4" STEAMVALVE 24V50/60C 00A,00D
008B 96P040V37 COIL 1/2"&3/4"STEAMVALVE 120V50/60C 00B,00E
008C 96P040V71 COIL 1/2"&3/4" STEAMVALVE 240V50/60 00C
009A 96V222TS TEFLON SPLITRING STEMVAL HAY6334-PC 00A,00B,00C
009B 96V222TSA TEFLON SPLITRING STEMVAL HAY6331-PC 00D,00E
012 96V250 PALNUT HAYS #3069-PC
013 96V251 SPRING WASHER HAYS#3600-PC
014 96V264 BOTTOMPLATE (COIL) #223601
015 96V262 FERRULE (COIL SLEEVE) #2239PC
******** END OF PARTS LIST ********
How to Read Parts List
Reference Item Numbers
—Items 00A, 00B, 00C, etc., or 00X, 00Y, 00Z, etc., appearing at the top of some parts lists, are for
reference and provide:
1. The part number for the entire assembly depicted in the drawing or a major sub-assembly thereof, and/or
2. The range of machine models this drawing applies to.
If more than one reference item appears, this usually means this drawing applies to more than one assembly (and thus to more than
one range of machines).
Component Item Numbers
—For any item on the drawing (e.g., item ➀), there may be several corresponding items on the parts
list (e.g., 001A, 001B, 001C, etc.) which are similar components on different assemblies. “How Part Is Used In Assembly” identifies which
components apply to your machine, by listing either the machine model, or the reference item number from the top of the parts list (e.g., 00A,
00B, 00C, etc.), or a particular characteristic (e.g., bronze or stainless steel), or special ordering information, such as a repair kit number.
BMP920028/92776V (Page 1)
1/2"& 3/4" HAYES ELECTRIC STEAM VALVES
