00A A33 07100C 93207#*DRASSY(INDNT)LK,LOGO N4,5,6P ALL MODELS EXCEPT M4A
00B A33 07100H 93207# DOOR ASY 3015/3020M4A 30015M4A+30020M4A ONLY
00C A33 06900F 93207@ ASSY=DOOR W/MLOGO DKRED 3022 3022F8J/F8P/F8W
001 X2 02814C 94267D DOOR=SHELL W/1LOK-3020
002 02 02819 88481C HINGE=STAMPED DOOR 25#
003 12P1AGHP1 HOLEPLUG LPE BLK 3/8"CAPLUG#BPF-3/8
006 02 02817 71108A FLANGE BRG=DOOR HINGE-NYLON
007A 02 09215D 93237D DR GLASS=N4,5,6P W/MIL LOGO 00A
007B 02 09215A 88452C DORGLAS=DRAW W/MILNOR LOGO 00B
007C 02 09215E 93237# DOOR GLASS W/MIL LOGO (RED) 00C
008 02 09021 79436A RING=DOOR GLASS PRESSURE
009 02 02366 93516A GASKET DOORGLAS GTR52-5220-3
010 02 10545 81116B EXTR BAND-STAMPED SS CYLDOOR
011 02 10342A GASKET=15" DOOR
012 02 02764 77482A HINGEPIN=SHELLDOOR L=10+5/8"
013 03 01420C 91062B DOOR STRIKER=ILOC
016 15G140 03Z HXCPNT 1/4-20 #C250=20 NKLPLT
017 15K031 BUTSOKCAPSCR 1/4-20X1/2 SS18-8
018 15U181 LOCKWASHER MEDIUM 1/4 SS18-8
019 24G020N ROLLED WASHER .252"ID NYLTITE #25W
020 60C080 RECESS BUMPER RUBBERLAVELLE #718-R
021 15P103 TRDCUT-F RDHDSLOT 8-32UNCX1/2 SS410
022 15N173A FLTMACSCR 1/4-20 UNCX5/8 UCUTSS18-8
023 20C044 ADHESIVE 3M EC-1300 IN PINT CONT.
024 15Q077 SOKSETSCR 1/4-20X1/4 ZINC ALLENONLY
025 03 01423C 86206B LATCH GUARD ILOC 3015-20
035 15U188 01Z FLTWASH 1/4 STD COMM SS18-8
036 15N191 FLATMACHSCR 1/4-20X7/8 SS18-8 U/CUT
037 03 01420D 87487Y DOOR HANDLE=ILOC 3015-20
******** END OF PARTS LIST ********
How to Read Parts List
Reference Item Numbers
—Items 00A, 00B,
00C, etc., or 00X, 00Y, 00Z, etc., appearing at the top of
some parts lists, are for reference and provide:
1. The part number for the entire assembly depicted in
the drawing or a major sub-assembly thereof, and/or
2. The range of machine models this drawing applies to.
If more than one reference item appears, this usually
means this drawing applies to more than one assembly (and
thus to more than one range of machines).
Component Item Numbers
—For any item on
the drawing (e.g., item ➀), there may be several corre-
sponding items on the parts list (e.g., 001A, 001B, 001C,
etc.) which are similar components on different assemblies.
“How Part Is Used In Assembly” identifies which compo-
nents apply to your machine, by listing either the machine
model, or the reference item number from the top of the
parts list (e.g., 00A, 00B, 00C, etc.), or a particular charac-
teristic (e.g., bronze or stainless steel), or special ordering
information, such as a repair kit number.
BMP920009/94491V (Page 2)
DOOR ASSEMBLY
30015 & 30020 RIGID MOUNT WASHER-EXTRACTORS
