Milnor C Series Service Manual

R
Pellerin Milnor CorporationPellerin Milnor Corporation
P. O. Box 400, Kenner, LA 70063-0400
Litho in U.S.A.
Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the "Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the parts list to the illustration.
Item
Part Number
Description
Comments
Used In
Parts List, cont.—Interlock Assembly
Parts List—Interlock Assembly
BMP750046/97341V
(Sheet 2 of 2)
. ---------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------------
A EDL00171 88093# INTRLKHSG ASSY=N/UNLOCK 240V 3015/20/22 MXX,CXX,
VXX
AA EDL00171A 93207@ RR PIVOT PL ASSY=N/UNLOK240V USED ON
00A(CONTAINS ITEMS 15-28)
B EDL00221 96411 INTRLKHSG ASSY=N/LOCK 220V 3022F8J/P/W
3630F8J/P/W/S
BB EDL00271A 93207#*RR PIVOT PL ASSY=N/LOCK 220V USED ON
00B(CONTAINS ITEMS 15-28)
C EDL00337 88093#*INTRLKHSG ASSY=N/LOCK 120V 36&42QXX,BWP 3015D4A CC EDL00337A 93207# RR PIVOT PL ASSY=N/LOCK 120V USED ON
00C(CONTAINS ITEMS 15-28)
D EDL00371 94000Z INTERLKHSG=N/LOCK+SWITCH240V 3015+3022K4X/54X
SINGLE MOTOR MODELS
DD EDL00271A 93207#*RR PIVOT PL ASSY=N/LOCK 220V USED ON
00D(CONTAINS ITEMS 15- )
-------------------------------------------------------------------COMPONENTS------------------------------------------------------------------ all 1 09R014A 05ZMIMI-SW SPDT STAKON #V15G1C26K all 2 03 01426 77201D HOUSING=FRONT=ILOC D only 2 03 01426A 94186D HOUSING=FRONT= ILOC W/UNLATC all 3 03 01427A 77181C HOUSING=REAR=ILOC (C-7) D only 3 03 01427B 94186D HOUSING=REAR=ILOC W/UNLATCH all 4 03 01429 75479C PLATE=FNT PIVOT=ILOC all 5 03 01335 INSULATOR=AUTOSPOT all 6 03 01425A 92683C DOOR HANDLE EXTENSION all 7 03 01423 75736B LATCH = INTERLOCK all 8 03 01417 75100B PLATE=SPACER=ILOC all 9 03 01418B 75194B KEEPER=LATCH PIN/NOTCH all 10 03 01418 75100B TAP STRIP=ILOC all 11 03 01424A 90501B STRIKER=SWITCH=LONG TAB
all 12 03 01442 92697B SOLENOID INSULATION=DR INTRK (NOT SHOWN) all 13 03 01443 84251AFLATHDRIVET 5/32X2+5/16 ZINC all 14 15H091 01Z STRGHTPIN 5/32''X2.25 LG ZINC AA,BB,DD 15 09K062B71 04Z SOLENOID 240/60--220/50 = ILOC CC 15 09K062B37 03Z SOLENOID(C-7)120/60--110/50 all 16 03 01428A 93207C PLATE=REAR PIVOT=ILOC (C-7) AA 17 03 01421B 93207B SLIDE=NORMALLY OPEN(C7 SOL) BB,DD 17 03 01421A 75736B SLIDE=NORMALLY LOCKED=ILOC CC 17 03 01421D 77341B SLIDE=NORMALLY LOCKED(C7-S) all 18 03 01425 75479B HANDLE=ILOC all 19 03 01422 94256C KEEPER=SPRING=ILOC all 20 03 01444A 77503B SPRING CUP = ILOC all 21 03 01444 82293ASPRING .51/1.69/46+CADPL all 22 03 01445 88481ASPRING .2/.625/.319+CADPL all 23 03 01445B 75935B TORQUE SPRING (.53 IN-#)CDPL all 24 03 01443 84251AFLATHDRIVET 5/32X2+5/16 ZINC all 25 15H090I STRAIGHT PIN 5/32"DIAX1.75"LG ZINC AA only 26 03 S1X1 88172B SHIM:DOOR INTLK SOLENOID N4P all 27 27B205080Z SPCRROLL.177ID.218L.027T STLZC B 27 27B205080E 01ZSPCRROLL.177ID.25L.027TK CSZNC BB,CC,DD 28 03 01418C 75736B KEEPER=NORMLOCKED SLIDE=ILOC
BMP750046/97341V (2 of 2)
