00P ESP71CME 89421N SWPNL 3015/20 MIC1 COIN MACH REFERENCE
00Q ESP71EP1PL 91171N SWPNL:3015/20 M4,5,6J EPPLUS REFERENCE
00R ESP71M1ME 88403N SWPNL 3015/20 SYS7HOTEL-MOT REFERENCE
00S ESP71M1HE 88403N SWPNL 3015/20 SYS7HLTHCARE REFERENCE
00T ESP71M1RE 88403N SWPNL 3015/20 SYS7RESTAURNT REFERENCE
00U ESP71M1AE 88403N SWPNL 3015/20 SYS7ATHLETIC REFERENCE
00V ESP71M1SE 88403N SWPNL 3015/20 SYS7SHIRT LAN REFERENCE
00W ESP71M1CE 88403N SWPNL 3015/20 SYS7COMMERCIL REFERENCE
00X ESP71M1OE 89131N SWPNL 3015/20 SYS7OFFSHORE REFERENCE
00Y ESP71M1JE 89392N SWPNL 3015/20 SYS7CORRECTIN REFERENCE
00Z ESP71M1FE 90436N SWPNL 3015/20 SYS7FAIRFIELD REFERENCE
001A 01 10531X 96143B NPLT 3015/22 M J-EP-PLUSISO 00Q
001B 01 10440 94297E GRAPHIC PANEL SYS 7 M4,5,6G 00R-00Z
001C 01 10457 94356E GRAPHIC PNL SYSTEM 7 COIN OOP
002A 01 10441A 90436C GPX PNL SYS7 HOTEL-MOTEL PRG 00R,00Y
002B 01 10441B 90436# GPX PNL SYS7 HEALTHCARE PROG 00S
002C 01 10441C 90436# GPX PNL SYS7 RESAURANT-PROG 00T
002D 01 10441D 90436# GPX PNL SYS7 ATHLETIC-PROG 00U
002E 01 10441E 90436# GPX PNL SYS 7 SHIRT LNDY-PRG 00V
002F 01 10441F 90436# GPX PNL SYS 7 COMMERC-PROG 00W
002G 01 10441G 90436#GRAPHIC PNL OFFSHORE PROG 00X
002H 01 10441K 90436# GRAP.PNL FAIRFIELD INN PROG. 00Z
003A 01 10442A 91393C GPX PNL SYS 7 HOTEL-MOTEL 00R
003B 01 10442B 91393# GPX PNL SYS 7 HEALTHCARE 00S
003C 01 10442C 91393# GPX PNL SYS 7 RESTAURANTS 00T
003D 01 10442D 91393# GPX PNL SYS 7 ATHLETIC 00U
003E 01 10442E 91393# GPX PNL SYS 7 SHIRT LAUNDRY 00V
003F 01 10442F 91393# GPX PNL SYS 7 COMMERCIAL 00W
003G 01 10442G 91393#GRAPHIC PNL OFFSHORE 00X
003H 01 10442J 91393# GPX PNL SYS 7 CORRECTIONAL 00Y
003I 01 10442K 91393# GRAPHIC PNL FAIRFIELD INN 00Z
004 03 E5X34 92356D ENCL:SYSTEM 7 GRAPHIC PNLMTG 00Z
005A 03 BU413U 92356D+BRKT:M4,5,6J LCD FILTER-EP10 00Q
005B 03 BU4X13 92356C BRKT:SYSTEM 7 LED FILTER 00P,00R-00Z
006 27B175I 01Z SPACER PLASTIC1/4ODX.175IDX1/4
007 27B17514SN 01Z SPACER .171IDX1/4ODX7/8LG NYLON NOT USED ON 00P
******** END OF PARTS LIST ********
How to Read Parts List
Reference Item Numbers
—Items 00A, 00B,
00C, etc., or 00X, 00Y, 00Z, etc., appearing at the top of
some
parts lists, are for reference and provide:
1. The part number for the entire assembly depicted in
the drawing or a major sub-assembly thereof, and/or
2. The range of machine models this drawing applies to.
If more than one reference item appears, this usually
means this drawing applies to more than one assembly (and
thus to more than one range of machines).
Component Item Numbers
—For any item on
the drawing (e.g., item
➀
), there may be several corre-
sponding items on the parts list (e.g., 001A, 001B, 001C,
etc.) which are similar components on different assemblies.
“How Part Is Used In Assembly” identifies which compo-
nents apply to your machine, by listing either the machine
model, or the reference item number from the top of the
parts list (e.g., 00A, 00B, 00C, etc.), or a particular charac-
teristic (e.g., bronze or stainless steel), or special ordering
information, such as a repair kit number.
BMP880028/96143V (Page 2)
SWITCH PANEL ASSEMBLY
30015, 30020 & 30022 MxG, MxJ, Cxx, K5x
