Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—Door Installation Components
------------------------------------------------------------------------------ASSEMBLIES------------------------------------------------------------
A ADL68001A 6836M5K 40DR CLOSED STRKR CENTER CUT
B ADL68012 6836M5K DOOR OPEN 180DEG LATCH/BUMP
C ADS60001 PRTS=40DRLG SECONDARY DR SW-RH
D GSD68004 6836M5K 48" DOOR RH
F GKE60002A INST=48"DOOR KNIFE 6836F
-----------------------------------------------------------------------------COMPONENTS-----------------------------------------------------------
All 1 02 10391 COVER STRIP=MICRO SW #6-8
all 2 20A015GA SHIM=FRICTION=CWU DOORSWITCH
all 3 09R008BSTD * 09R008B+MOUNTING HDWRE+INST
all 4 15K031 BUTSOKCAPSCR 1/4-20X1/2 SS18-8
all 5 15U181 LOCKWASHER MEDIUM 1/4 SS18-8
all 6 15K173A HXCAPSCR 1/2-13UNC2AX1.75 GR5
all 7 15U300 LOKWASHER REGULAR 1/2 ZINC PLT
all 8 15U490 FLTWASH 1+1/2X17/32X1/4 ZINC
all 9 W3 60775 WLMT=LATCH STRIK 40"DR LG
all 10 W3 60778B 6836M5K STRKR CVR 40" DOOR CENTER CUT
all 11 W2 22714 6836M5K OPEN DOOR LATCH/BUMPER WLMT
all 12 SA 15 028 * DOOR LATCH ASSY-DIVCYLS
all 13 60E004TE 1/4"OD X.170"ID NYL(BLK)TUBING
all 14 53A031B BODY-EL90MALE.25X1/8 #269C-42B
all 15 60C075 TRUCK BUMPER 2+1/2ODW3/8HO.613
all 16 15K110 HEXCAPSCR 3/8-16UNC2AX1.5 GR5-
all 17 15U240 FLATWASHER(USS STD) 3/8" ZNC P
all 18 15U245A FLTWASH 25/64IDX1.25ODX3/32 S/
all 19 15U255 LOCKWASHER MEDIUM 3/8 ZINCPL
all 20 15G205 HXNUT 3/8-16UNC2B ZINC GR2
all 21 09RPS18CAS PRXSW QKCO 18M NO-AC SHLD
all 22 09RPTAC095 CONN. 90 FEM 3-PIN AC 3A 5M
all 23 53A059A NUT 1/4"BR.HOLYOKE AND #61A-4
all 24 53A500 SLEEVE DELRIN 1/4"OD#60PT-4
all 25 53A501 TUBE INSERT .163"OD #63PT-4-40
Page (3 / 4)
PELLERIN MILNOR CORPORATION
BMP150043/2015155A
Door Installation Components
68036M5K, 72046M5K
116
