Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—Door Installation Components
all 26 02 15633S ADJPLATE=DOORLATCH SS
all 27 15K105 HXCAPSCR 3/8-16UNC2A1.25 GR5 P
all 33 09RM02212S CAPSW 12' 180DEG ROLLER SILVER
all 34 03 60782A SECOND DR SWTCH BKT-HVY HNGE
all 35 15K084S HXCAPSCR 3/8-16NCX5/8 SS18-8
all 36 15U245 FLTWASH 3/8 STD COMM 18-8 SS
all 37 15U260 LOCKWASHER MEDIUM 3/8 SS18-8
all 38 W3 65338F 6836M5K UNLOAD TRAY WLMT
all 39 15K112 HXCAPSCR 3/8-16X1+1/2 SS18-8
all 41 15U491 FLTWASH 1.439OD.394ID.120TH188
all 42 Y5 75860 MACH=KNIFE EDGE 48" DOOR, 6836
all 43 03 60864 1/8"GASKET=KNIFE RING 48"DR
all 44 03 60864A 1/16"GASKET=KNIFE RING 48"DR
all 45 20C040B SUPERFLEX CLR RTV SIL 10.2OZ
all 46 02 22807 6836M5K DOOR OPEN PROX MOUNT
all 47 96M055 DELTROL QUICK EXHAUST VLV.1/4"
Page (4 / 4)
PELLERIN MILNOR CORPORATION
BMP150043/2015155A
Door Installation Components
68036M5K, 72046M5K
117
