Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—48” Door
--------------------------------------------------------------------ASSEMBLIES----------------------------------------------------------------------------------------------------
A ADC60002 ASSY=48"DOOR CHN W/2AIR BSK
B ASD60002 ASSY=48"DOOR 304 W/GLASS
C ADG60002 PRTS=48"DR LG GLASS MNT 304
-------------------------------------------------------------------COMPONENTS--------------------------------------------------------------------------------------------------
all 1 W3 60865 WLMT=OUTER CHANNEL 48"DR LG
all 2 W3 60866 WLMT=INNER CHNL 48" DR MD1
all 3 02 18187S SPRING=DOOR STAINLESS STEEL
all 4 15K203T HEXCAPSCR 1/2-13X6 GR5 ZINC
all 5 15K203TA HEXCAPSCR 1/2-13X6.5 GR8 ZINC
all 6 27B2750L0T SPC RROLL.562ID.937L.048T ZNK
all 7 15U280 FL+WASHER(USS STD)1/2 ZNC PL+D
all 8 15G234 LOKNUT 1/2-13NC CAD FLXLOC#21F
all 9 60B100 AIRMT S116B 1CONV F3582017564
all 10 15K095 HXCPSCR 3/8-16UNC2AX1 GR5 ZINC
all 11 15U255 LOCKWASHER MEDIUM 3/8 ZINCPL
all 12 60E004TE 1/4"OD X.170"ID NYL(BLK)TUBING
all 13 53A031B BODY-EL90MALE.25X1/8 #269C-42B
all 14 53A059A NUT 1/4"BR.HOLYOKE AND #61A-4
all 15 53A500 SLEEVE DELRIN 1/4"OD#60PT-4
all 16 53A501 TUBE INSERT .163"OD #63PT-4-40
all 17 51V015 TEE 1/4 FGDBRASS 101T7-444
all 18 12P1AGSB SNAPBUSH 3/8"MH X 1/4" T=1/8
all 19 03 60886 BRKT=EXAUST VALVE/48"DOOR
all 20 ADH60001 PRTS=40"DR LG HINGE CRB
all 21 15K214E HXCAPSCR 5/8-11UNC2AX1.5 GR5 Z
all 22 15U314 FLATWASHER(USS STD) 5/8" ZNC P
all 23 15U315 LOKWASHER MEDIUM 5/8 ZINCPL
all 24 15G238 HXNUT 5/8-11UNC2B SAE ZINC GR2
all 25 SA 15 028 * DOOR LATCH ASSY-DIVCYLS
all 26 02 15633S ADJPLATE=DOORLATCH SS
all 27 15K110 HEXCAPSCR 3/8-16UNC2AX1.5 GR5-
all 31 60E005 TUBING BLK.POLY.5/160DX3/16ID
all 32 53A040B BODY=EL90MALE5/16X.25#B69A-5B
all 33 53A020B BODYMALECON5/16X.25COM#B68A-5B
all 34 53A060A NUT BRASS 5/16 COMP#61A-5
all 35 53A508 SLEEVE DELRIN 5/16"OD#60PT-5
All 36 53A509 TUBE INSERT 5/16"OD X .53"LG.
Page (4 / 5)
PELLERIN MILNOR CORPORATION
48” Door
BMP120047/2015155A
68036H5N, 68036H5K, 68036M5K, 72046M5K
126
