Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—48” Door
all 37 12P1AHSB SNAPBUSH .437"MH X .312" T=1/8
all 38 27A005 MUFFLER 3/8" BANTAM B38
all 39 96M055 DELTROL QUICK EXHAUST VLV.1/4"
all 40 15K041 HXCAPSCR 1/4-2OUNC2AX1 GR 5 ZI
all 41 15U180 LOCKWASHER MEDIUM 1/4 ZINCPL
all 42 15G165 HXNUT 1/4-20UNC2BSAE ZC GR2
all 43 03 60869 48"DOOR-SHIM=1/8"
all 44 03 60869A 48" DOOR SHIM=1/4"
all 45 03 60851 GASKET=48"DOOR EPDM
all 46 03 60855 GLASS=48"DR 3/8T X 41.75 OD
all 47 X3 60850 MACH=48" DOOR
all 48 15G206 HEXNUT 3/8-16 UNC2 SS 18-8
all 49 15N223A FLATMACHSCR 3/8-16X1+1/2 SS SL
all 50 15U245 FLTWASH 3/8 STD COMM 18-8 SS
all 51 15U245B FLATWASH SPECIAL DOOR 52+72
all 52 15U260 LOCKWASHER MEDIUM 3/8 SS18-8
all 53 03 60856 GASKET=GLASS 48"DOOR 42.06DIA
all 54 27B2400K0L SPACER ROLL.43ID.562L.03T SS
all 55 X3 60857 MACH=48"DR GLSS MNT RING LG
all 56 15G200 HXCPNUT 3/8-16 UNC2A 5/8X1/2
all 57 15K106B BUTSOKCAPSCR 3/8-16NCX1+3/8 SS
all 59 24G030N ROLLED WASH.379ID NYLTITE 37W
all 60 03 60867 VERT CHANNEL 48" DOOR
all 61 03 60868 LFT MNT PLATE=VERT CHN/48"DR
all 62 03 60868A RT MNT PLATE=VERT CHN/48"DR
all 63 03 60868B NUT PLATE=VERT CHN/48"DOOR
all 64 03 60868C SPACER=VERT CHNL/48"DOOR
all 65 W3 60780A WLMT=48" DOOR HINGE BRKT
all 66 W5 20017 * WELDMENT=40" DOOR HINGE
all 67 54JH13562B HINGE COL SPLIT 3.56 FL TOP
all 68 15K041E SKCPSCR 1/4-20X1+1/4"BLK
all 69 54A976977 TIMKN #L44610/L44643=1.00"BORE
all 70 05 20140A PIN-DOOR HINGE 15.625LG 72T
all 71 54M015 GREASEFIT 60X36/60X44 1610BL
all 72 15G248 HXJAMNUT 1-14UNF2B ZINC GR2
all 73 15G249 HXCAPNUT L-CROWN 1-14UNF2B ZIN
all 74 05 20017E SHIM=DOOR HINGE 11 GA 64D
All 75 05 20017F SHIM=DOOR HINGE 16 GA 64D
