Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—Safety Light Screen Components & Installation
PELLERIN MILNOR CORPORATION
--------------------------------------------------------------------------------------------COMPONENTS------------------------------------------------------------------
all 1 09RPE018LBG STND FOR SENDER , RECEIVER, MIRROR
all 2 09RPE018LBF CORNER MIRROR BRACKETS
all 3 09RPE018LBE CORNER MIRROR FOR SAFETY BEAM
all 4 09RPE018LBA LITE BEAM EMITTER/RECEIVER 600MM BANNER
all 5 09RPE018LBB LITE BEAM CORDSET 15.3 METER
all 6 09H025V71 BEACON ROTARY 8.5"DIA AMBER
all 7 09RPE018LBC LITE BEAM MUTING RELAY MODULE NOT SHOWN
all 8 09RPE018LBD LITE BEAM SAFETY RATING 24VDC POWER SUPPLY NOT SHOWN
all 9 09N127C KEYSW SPST 7A120VAC SCREW TERM NOT SHOWN
all 10 01 10760X NPLT:LIGHT CURTAIN BYPASS>ISO NOT SHOWN
48040M7K, 68036M5K, 72046M5K
Page (3 / 3)BMP150061/2016046A
Safety Light Screen Components & Installation
