Item
Part Number
Description
Comments
Used In
Find the correct assembly first, then find the needed components. The item letters (A, B, C, etc.) assigned to assemblies are referred to in the
"Used In" column to identify which components belong to an assembly. The item numbers (1, 2, 3, etc.) assigned to components relate the
parts list to the illustration.
Parts List—Guards and Covers
PELLERIN MILNOR CORPORATION
Page (5 / 5)
B 4 W2 25118 7246M5K BRAKE COVER WLMT
all 5 W2 25108 7246M5K MOTOR/JACKSHAFT BELTGUARD WLMT
all 6 02 25109 7246M5K MOTOR/JACK BELTGUARD STIFFENER
A 7 AGS68002 6836M5K REAR BELT GUARD ASSEMBLY
B 7 AGS72001 7246M5K REAR BELT GUARD ASSY
C 7 AGS48010 4840M7K BELTGUARD ASSY LEFT 48040 LEFT BELT GUARD
C 7 AGS48010A 4840M7K BELTGUARD ASSY RIGHT 48040 RIGHT BELT GUARD
A 8 02 22677 6836M5K BELT COVER MOUNT BRKT
B 8 02 25106 7246M5K BELT COVER MOUNT BRK
C 8 02 24041 4840M7K BELTGUARD MOUNT BRKT LT 48040 LEFT BRACKET
C 8 02 24041A 4840M7K BELTGUARD MOUNT BRKT RT 48040 RIGHT BRACKET
all 9 X2 22700 6836M5K BELT COVER PIVOT SHAFT
all 10 17B012 EXTRETRING IND#1000-50-ST-ZD Z
A 11 02 22775 6836M5K TRUCK BUMPER BRKT
B 11 02 25107 7246M5K TRUCK BUMPER BRKT
all 12 60B075 DFW56-33PMSP RUBB CONN.
all 13 02 22676 6836M5K BELT COVER LOCK BRKT
all 14 02 25121A 7246M5K BELTGUARD UPPER FILLER
AB 15 AGS75001L COVER=GEARTRAIN LH
C 15 02 21968A EXTENDED COVER=CHAIN COUPLING, 4840F TORQUE MOTOR BELOW
DOOR
all 16 15K085 HEXCAPSCR 3/8-16UNC2AX3/4 GR5
all 17 15G198 HXFLGNUT 3/8-16 ZINC
all 18 15U200 FLATWASHER(USS STD) 5/16"ZNC P
all 19 15K117 HEXCAPSCR 3/8-16X1+3/4 GR 5 PL
all 20 15U240 FLATWASHER(USS STD) 3/8" ZNC P
all 21 15U516 FLTWSHR 2.5ODX17/32"IDX.25"THI
all 22 15G201 HXLOKNUT 3/8-16 NYL/SS TYPE NE
all 23 15K145 HXCAPSCR 1/2-13UNC2AX3/4 GR5 P
all 24 15U280 FL+WASHER(USS STD)1/2 ZNC PL+D
all 25 15U300 LOKWASHER REGULAR 1/2 ZINC PLT
all 26 15K086 HXCAPSCR 3/8-16NCX3/4 SS18-8
all 27 15U246 FLATWASHER 1"ODX25/64IDX1/8"30
all 28 15U260 LOCKWASHER MEDIUM 3/8 SS18-8
all 29 15K083V BUTSOKCAPSCR 3/8-16X3/4 SS18-8
all 30 15P185 TRDCUT-F HXHD 1/4-20UNC2AX3/4
C 31 02 24056 4840M7K BELTGUARD APEX
BMP150029/2015443A
Guards and Covers
48040M7K, 68036M5K, 72046M5K
38
