Milnor MWF C Series Installation And Service

Cylinder Installation 68036F5N, 68036H5N, 68036H5K, 68036M5K, 72046M5K
PELLERIN MILNOR CORPORATION
Figure 2: Shell front, Shell, Cylinder
Detailed views
Legend
A. Detailed view, Top connection between the shell front and the shell side sheet
B. Detailed view, Bottom connection between the shell front and the shell side sheet
.
Figure 3: Shell rear, Bearing housing
Detailed views
Legend
C. Detailed view, Connection between the shell rear and the bearing housing, Top
D. Detailed view, Connection between the shell rear and the bearing housing, Bottom
L. 2 instances
M. 8 instances
.
