Milnor MWF C Series Schematic/Electrical Parts

C O M P O N E N T P A R T S L I S T
W6H3NZPL/2021022N
COMPONENT FUNCTION OF THIS WHERE TO FIND NUMBER COMPONENT NUMBER THIS COMPONENT MILNOR P/N DESCRIPTION LOCATION VEC06 VALVE-CHEMICAL #6 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC07 VALVE-CHEMICAL #7 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC08 VALVE-CHEMICAL #8 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC09 VALVE-CHEMICAL #9 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC10 VALVE-CHEMICAL #10 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC11 VALVE-CHEMICAL #11 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC12 VALVE-CHEMICAL #12 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC13 VALVE-CHEMICAL #13 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC14 VALVE-CHEMICAL #14 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEC15 VALVE-CHEMICAL #15 W6H3NZCX MESSAGE EW SUPPLIED BY OTHERS SUPPLY VLVST VEDL VALVE-DOOR UNLATCH W6H3NZS+A 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BOX
VEDL VALVE-DOOR UNLATCH W6H3NZS+ 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BOX
VEDRR VALVE-REUSE DRAIN W6H3NZEV 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX
VEDRR VALVE-REUSE DRAIN W6H3NZEVA 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX
VEDRS VALVE-DRAIN W6H3NZEV 96D350A71 DRINVAL 3"MTRDR 240V 50/60C REAR OF MACH VEDRS VALVE-DRAIN W6H3NZEVA 96D350A71 DRINVAL 3"MTRDR 240V 50/60C REAR OF MACH VEEB1 VALVE-BALANCE RIB 1 W6H3NZEB2 96P053A71 3/4"VALVE 240V HAYS#6-2110IS-240 REAR OF MACH VEEB2 VALVE-BALANCE RIB 2 W6H3NZEB2 96P053A71 3/4"VALVE 240V HAYS#6-2110IS-240 REAR OF MACH VEEB3 VALVE-BALANCE RIB 3 W6H3NZEB2 96P053A71 3/4"VALVE 240V HAYS#6-2110IS-240 REAR OF MACH VEFL VALVE-FLUSH W6H3NZCF 96P013G71 3/4" 2WAYPLASTCVAL 240V/60C SUPPLY INJEC VEHDC VALVE-HYDRAULIC DOOR CLOSED W6H3NZHD 96RH706E71 VLVPARKER 220V50/240V60 7GPM MACHINE REAR VEHDC VALVE-HYDRAULIC DOOR CLOSED W6H3NZHDA 96RH706E71 VLVPARKER 220V50/240V60 7GPM MACHINE REAR VEHDO VALVE-HYDRAULIC DOOR OPEN W6H3NZHD 96RH706E71 VLVPARKER 220V50/240V60 7GPM MACHINE REAR
VEHDO VALVE-HYDRAULIC DOOR OPEN W6H3NZHDA 96RH706E71 VLVPARKER 220V50/240V60 7GPM MACHINE REAR
VEHTD VALVE-HYDRAULIC TILT DOWN W6H3NZRH 96RH711E71 DIRECTIONAL CNT VLV D05NG10 230V MACHINE REAR VEHTU VALVE-HYDRAULIC TILT UP W6H3NZRH 96RH711E71 DIRECTIONAL CNT VLV D05NG10 230V MACHINE REAR VEMTM VALVE-MACHINE TO MACHINE W6H3NZEV 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX
VEMTM VALVE-MACHINE TO MACHINE W6H3NZEVA 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX
VEMTT VALVE-MACHINE TO TANK W6H3NZEV 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX VEMTT VALVE-MACHINE TO TANK W6H3NZEVA 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX VEPPO VALVE-DOOR SEAL W6H3NZS+A 96R302A71 1/8" AIRPILOT 3W NO 240V50/60 AIR VALVE BOX
VEPPO VALVE-DOOR SEAL W6H3NZS+ 96R302A71 1/8" AIRPILOT 3W NO 240V50/60 AIR VALVE BOX VESTM VALVE-STEAM W6H3NZEV 96R301A71 1/8" AIRPILOT 3W NC 240V50/60 AIR VALVE BX
Page 7 of 8
7
