Milnor MWF C Series Schematic/Electrical Parts

C O M P O N E N T P A R T S L I S T
W6H3NZPL/2021022N
COMPONENT FUNCTION OF THIS WHERE TO FIND NUMBER COMPONENT NUMBER THIS COMPONENT MILNOR P/N DESCRIPTION LOCATION
>>>CONTROL BOX LAYOUTS
01 DETAIL-LOW VOLTAGE CONTROL BOX W6H3NZTG1 B2T2014006
48040H7R/K LOW VOLT C-BOX
SEE FUNCTION
02 DETAIL-HIGH VOLTAGE CONTROL BOX - 68 & 72M5K W6H3NZTG1 B2T2014015 48/68/72 H/M 7/5 R/K HV BOX SEE FUNCTION 03 DETAIL-HIGH VOLTAGE CONTROL BOX - 48M5K W6H3NZTG2 B2T2015005 48M7R/K HV BOX SEE FUNCTION 04 DETAIL-POWER SUPPLIES W6H3NZTG2 B2T2014012 MILTOUCH-EX POWER SUPY SET SEE FUNCTION 05 DETAIL-CONTROL BOARDS INPUTS/OUTPUTS W6H3NZTG3 B2T2014013 MTOUCH-EX W/E BDS IN/OUT LIST SEE FUNCTION 06 DETAIL-VALVE SET W6H3NZTG3 B2T2015003 48M7K, 68-72M5K VALVES SEE FUNCTION ACBA >>>ACCELEROMETERS ACBA BOARD-ACCELEROMETER W6H3NZEB1 EACCLRM5 ASSY:ACCEL 1-5G ADXL 105+TEST DOOR LATCH ACBA BOARD-ACCELEROMETER W6H3NZEC EACCLRM5 ASSY:ACCEL 1-5G ADXL 105+TEST DOOR LATCH BA >>>PRINTED CIRCUIT BOARDS BAD-1 BOARD-ANALOG TO DIGITAL CONVERTER W6H3NZBW 08BSADCT BD: SERIAL A-D CONVERT->TEST CONTROL BOX BAS BOARD-16 SNUBBER CIRCUITS W6H3NZCF 08BNCMBT COIN MACHINE SNUBBER->TESTED CONTROL BOX BAS BOARD-16 SNUBBER CIRCUITS W6H3NZEV 08BNCMBT COIN MACHINE SNUBBER->TESTED CONTROL BOX BAS BOARD-16 SNUBBER CIRCUITS W6H3NZEVA 08BNCMBT COIN MACHINE SNUBBER->TESTED CONTROL BOX BBAD-1 BOARD-BALANCE A-D W6H3NZEB1 08BSBADCTE SR BALANCE A-D BD EXTACTR-TEST CONTROL BOX BBAD-1 BOARD-BALANCE A-D W6H3NZEC 08BSBADCTE SR BALANCE A-D BD EXTACTR-TEST CONTROL BOX BDA-1 BOARD-DIGITAL TO ANALOG CONVERTOR W6H3NZBW 08BSDACHT BD:HI-RES SERIAL D-A->TEST CONTROL BOX BIO-1 BOARD-8OUTPUT/16INPUT #1 W6H3NZBW 08BS816CHT BD 8OUT-16IN HIGH SPD->TEST CONTROL BOX BIO-2 BOARD-8OUTPUT/16INPUT #2 W6H3NZBW 08BS816CHT BD 8OUT-16IN HIGH SPD->TEST CONTROL BOX BLB BOARD-LEVEL TRANSDUCER W6H3NZBW 08BNLTT LEVEL TRANSDUCER BD->TEST CONTROL BOX BMTH-1 BOARD-3 CHANNEL MOTHER W6H3NZBW 08BS3MTHAT BD:SERIAL 3 CARD MOTHER->TEST CONTROL BOX BMTH-1 BOARD-3 CHANNEL MOTHER W6H3NZEB1 08BS3MTHAT BD:SERIAL 3 CARD MOTHER->TEST CONTROL BOX BMTH-2 BOARD-3 CHANNEL MOTHER W6H3NZBW 08BS3MTHAT BD:SERIAL 3 CARD MOTHER->TEST CONTROL BOX BO24-1 BOARD-24 OUTPUT #1 W6H3NZBW 08BSO24AT BD:SERIAL 24 OUTPUT->TEST CONTROL BOX BO24-2 BOARD-24 OUTPUT #2 W6H3NZBW 08BSO24AT BD:SERIAL 24 OUTPUT->TEST CONTROL BOX BO24-3 BOARD-24 OUTPUT #3 W6H3NZBW 08BSO24AT BD:SERIAL 24 OUTPUT->TEST CONTROL BOX BPB BOARD-ARM9 PROCESSOR+TOUCH SCREEN W6H3NZBW 08BHA9D4T ASSY:ARM9 PROC+8.4 OPTREX DSP-TESTED PROCESSOR BX BSP BOARD-SPEED SENSING W6H3NZBW 08BNDSRAT BD DRY SAFETY ROTATION->TEST CONTROL BOX CB >>>CIRCUIT BREAKER CB1 CIRCUIT BREAKER-HYDRAULIC PUMP W6H3NZVP 09FC016CAA IEC MINI CIR.BREAK 16A 480V3P CONTROL BOX CB2 CIRCUIT BREAKER-RECIRCULATION PUMP W6H3NZVP 09FC010CAA IEC MINI CIR.BREAK 10A 480V3P CONTROL BOX CD >>>RELAY DELAY
