Milnor MWF C Series Schematic/Electrical Parts

C O M P O N E N T P A R T S L I S T
W6H3NZPL/2021022N
COMPONENT FUNCTION OF THIS WHERE TO FIND NUMBER COMPONENT NUMBER THIS COMPONENT MILNOR P/N DESCRIPTION LOCATION CDDH DELAY-HDRAULIC DOOR OPEN > 3/6/2019 W6H3NZRH 09CF001071 TDR F1S 2PDT 11PIN 240V60C CONTROL BOX CDDH DELAY-HDRAULIC DOOR OPEN < 3/6/2019 W6H3NZRH 09CA0100A71 ADJUSTABLE TIME DELAY 10S OMRON 200-2
3
CONTROL BOX
CL >>>RELAY-LATCH CLA LATCH-DOOR SEAL W6H3NZS+A 09CL2C-C71 RELAY-LATCH DPDT 240V 2-COIL CONTROL BOX CLA LATCH-DOOR SEAL W6H3NZS+ 09CL2C-C71 RELAY-LATCH DPDT 240V 2-COIL CONTROL BOX CLA-CHOKE CHOKE-DOOR SEAL LATCH W6H3NZS+A 10YCLCHOKE LATCH HARNES: RF CHOKE CONTROL BOX CP >>>PHOTOEYE CPLC LIGHT CURTAIN-EMITTER/RECEIVER W6H3NZLC 09RPE018LBA LITE BEAM EMITTER/RECEIVER 600MM BANN
E
SIDE OF MACH
CPLCC LIGHT CURTAIN-EMITTER/RECEIVER W6H3NZLC 09RPE018LBC LITE BEAM MUTING RELAY MODULE LOW VOLT BOX CPSP PHOTOEYE-SPEED W6H3NZBW 09RPE013Q SENSOR E-Z BEAM QUICK CONN DC MAIN PULLEY CR >>>RELAY-PILOT OR CONTROL CRA RELAY-DOOR SEALED W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRA RELAY-DOOR SEALED W6H3NZS+ 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRAD RELAY-BASE BLOCK ON MILTOUCH POWER UP W6H3NVVP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED LOW VOLT BOX CRBO RELAY-BEAM OK W6H3NZLC 09C024E24 RELAY 4PDT DIFGLD 14PIN 24DC CONTROL BOX CRBO RELAY-GATE IS CLOSED W6H3NZLC 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRBSL RELAY-SPEED IS AT OR ABOVE DRAIN SPEED W6H3NZLC 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRC01 RELAY-INTERPRET RELAY #1 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC02 RELAY-INTERPRET RELAY #2 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC03 RELAY-INTERPRET RELAY #3 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC04 RELAY-INTERPRET RELAY #4 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC05 RELAY-INTERPRET RELAY #5 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC06 RELAY-INTERPRET RELAY #6 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC07 RELAY-INTERPRET RELAY #7 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC08 RELAY-INTERPRET RELAY #8 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC09 RELAY-INTERPRET RELAY #9 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC10 RELAY-INTERPRET RELAY #10 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC11 RELAY-INTERPRET RELAY #11 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC12 RELAY-INTERPRET RELAY #12 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC13 RELAY-INTERPRET RELAY #13 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC14 RELAY-INTERPRET RELAY #14 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRC15 RELAY-INTERPRET RELAY #15 W6H3NZCP 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED INT RELAY BX CRD RELAY-DOOR UNLATCH W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX
Page 2 of 8
2
