Milnor MWF C Series Schematic/Electrical Parts

C O M P O N E N T P A R T S L I S T
W6H3NZPL/2021022N
COMPONENT FUNCTION OF THIS WHERE TO FIND NUMBER COMPONENT NUMBER THIS COMPONENT MILNOR P/N DESCRIPTION LOCATION CRD RELAY-DOOR UNLATCH W6H3NZS+ 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRDB RELAY-RESISTOR TEMP HIGH W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRDB RELAY-DOOR UNLATCH HIGH W6H3NZS+ 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRDOA RELAY-DOOR FULL OPEN W6H3NZRH 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CREI RELAY-DOOR OPEN AND UNLATCHED W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CREI RELAY-OK TO JOG W6H3NZS+ 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRLPB RELAY-LIGHT BEAM BY PASS W6H3NZLC 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRS+ RELAY-START 3-WIRE W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRS+ RELAY-START 3-WIRE W6H3NZS+ 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRS+A RELAY-START 3-WIRE (SLAVE) W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRS+B RELAY-START 3-WIRE (SLAVE) W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRSG RELAY-SIGNAL FOR ROTATION LED BEACON W6H3NZS+A 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CRWJ RELAY-JOG W6H3NZHDA 09C024D71 RELAY 4PDT DIFGLD 14PN 240V W/LED CONTROL BOX CS >>>CONTACTOR-MOTOR STARTER CSDO CONTACTOR-HYDRAULIC PUMP W6H3NZHD 09MC08C371 16A 3P MCS CONT NR 240V5/6 CONTROL BOX
CSDO CONTACTOR-HYDRAULIC PUMP W6H3NZRH 09MC08C371 16A 3P MCS CONT NR 240V5/6 CONTROL BOX
CSR CONTACTOR-RECIRCULATE W6H3NZEV 09MC04E371 32A 3P CONT.NR 240V5/6 IEC CONTROL BOX CSR CONTACTOR-RECIRCULATE W6H3NZEVA 09MC04E371 32A 3P CONT.NR 240V5/6 IEC CONTROL BOX CSVP CONTACTOR-INVERTER 48040 LOW VOLTAGE W6H3NZS+A 09MC08N371 72A 3P MCS CONT NR 240V5/6 CONTROL BOX CSVP CONTACTOR-INVERTER 68036 LOW VOLTAGE W6H3NZS+A 09MC08T371 115A 3P MCS CONT. NR 240V5/6 CONTROL BOX CSVP CONTACTOR-INVERTER 48040 LOW VOLTAGE W6H3NZS+ 09MC08N371 72A 3P MCS CONT NR 240V5/6 CONTROL BOX
CSVS CONTACTOR-INVERTER 48040 HIGH VOLTAGE W6H3NZS+A 09MC08G371 37A 3P MCS CONT NR 240V5/6 CONTROL BOX CSVS CONTACTOR-INVERTER 68036 HIGH VOLTAGE W6H3NZS+A 09MC08N371 72A 3P MCS CONT NR 240V5/6 CONTROL BOX CSVS CONTACTOR-INVERTER 48040 HIGH VOLTAGE W6H3NZS+ 09MC08G371 37A 3P MCS CONT NR 240V5/6 CONTROL BOX EB >>>BUZZER OR AUDIBLE SIGNAL EBSG BUZZER-SIGNAL AUDIBLE W6H3NZS+A 09H016 BUZZ. 230V W/6-32 CTR+6" LEADS SWITCH PANEL EBSG BUZZER-SIGNAL AUDIBLE W6H3NZS+ 09H016 BUZZ. 230V W/6-32 CTR+6" LEADS SWITCH PANEL
EF >>>FUSE OR FUSE HOLDER EF01 FUSE-CONTROL CIRCUIT W6H3NZLV 09FF006AMA FUSE BK/ABC 6 AMP 250V BUSS CONTROL BOX EF02 FUSE-CONTROL CIRCUIT W6H3NZLV 09FF006AMA FUSE BK/ABC 6 AMP 250V BUSS CONTROL BOX EF1 FUSE-PRIMARY INCOMING VOLTAGE W6H3NZLV 09FF005AWN BUSE BUSS KTK 5AMP 600V=HPS HOLDER CONTROL BOX EF2 FUSE-PRIMARY INCOMING VOLTAGE W6H3NZLV 09FF005AWN BUSE BUSS KTK 5AMP 600V=HPS HOLDER CONTROL BOX EL >>>LIGHT-PILOT OR INDICATOR
Page 3 of 8
3
