Milnor MWF C Series Schematic/Electrical Parts

C O M P O N E N T P A R T S L I S T
W6H3NZPL/2021022N
COMPONENT FUNCTION OF THIS WHERE TO FIND NUMBER COMPONENT NUMBER THIS COMPONENT MILNOR P/N DESCRIPTION LOCATION ELLB-E/R LIGHT CURTAIN-EMITTER/RECEIVER W6H3NZLC 09RPE018LBA LITE BEAM EMITTER/RECEIVER 600MM BANN
E
CONTROL BOX
ELLB-PS LIGHT CURTAIN POWER SUPPLY W6H3NZLC 09RPE018LBD LITE BEAM SAFETY RATING 24VDC PWR SPL
Y
CONTROL BOX
ELLB-RM LIGHT CURTAIN RELAY MODULE W6H3NZLC 09RPE018LBC LITE BEAM MUTING RELAY MODULE CONTROL BOX ELLPB LIGHT-LIGHT BEAM BY PASSED BEACON W6H3NZLC 09H025V71 BEACON ROTARY 8.5"DIA AMBER TOP OF CNTR BX ELLPB LIGHT-LIGHT BEAM BY PASSED LED BEACON W6H3NZFS 09H025V12 BEACON ROTARY AMBER LED 12VDC TOP OF CNTR BX ELSG LIGHT-SIGNAL VISUAL W6H3NZS+A 09J060A71 LAMP 1/2" AMB 250V IDI 1051QC3 SWITCH PANEL ELSG LIGHT-SIGNAL VISUAL W6H3NZS+ 09J060A71 LAMP 1/2" AMB 250V IDI 1051QC3 SWITCH PANEL ELSG LIGHT-OPTIONAL ROTATION LED BEACON W6H3NZFS 09H025V12 BEACON ROTARY AMBER LED 12VDC TOP OF CNTR BX EM >>>METERS EMHR METER-RUN TIME IN HOURS W6H3NZFS 38C203 HOUR METER 3.8IN 3 HOLE MTG 230V/60C CONTROL BOX ES >>>POWER SUPPLY-ELECTRONIC ESLC POWER SUPPLY-LIGHT CURTAIN W6H3NZLC 09RPE018LBD LITE BEAM SAFETY RATING 24VDC POWER S
U
LOW VOLT BOX
ESPS POWER SUPPLY-CARD CAGE W6H3NZBW 08PSS3401T 40 WATT POWER SUPPLY TESTED CONTROL BOX ESPS-2 POWER SUPPLY-MICROPROCESSOR W6H3NZBW 08PSS2401T PRW SUPY 40WATT 120/240V TO 12V TESTED CONTROL BOX ESPS-2 POWER SUPPLY-OPTIONAL BEACON LIGHT W6H3NZFS 08PSS2401T PRW SUPY 40WATT 120/240V TO 12V TESTED CONTROL BOX ET >>>THERMAL OVERLOAD DEVICES ETDO OVERLOAD-HYDRAULIC PUMP MOTOR W6H3NZHD 09FTD0037T MCS OL RELAY ADJ. RANGE 3.7-12 CONTROL BOX ETDO OVERLOAD-HYDRAULIC PUMP MOTOR W6H3NZRH 09FTD0037T E1 PLUS OL RELAY 3.2-16A CONTROL BOX ETVS OVERLOAD-VARIABLE SPEED INVERTER W6H3NZVP 09FTD0230T MCS OL RELAY ADJ. RANGE 23-75 CONTROL BOX EX >>>TRANSFORMERS EX37-1 TRANSFORMER-208 TO 240V W6H3NZLV 09UB25AU71 AUTOXFMR 208V/230V 250VA UL/CSA CONTROL BOX EX37-2 TRANSFORMER-380/480 TO 240VAC W6H3NZLV 09UA025AAB XFMR 380-480PRI/120-240SEC250V CONTROL BOX EX96A TRANSFORMER-600V TO 480V -48040H7 W6H3NZMT6 09US050A96 XFMR 1PH 5KVA 240/480X120/240 SIDE OF MACH EX96A TRANSFORMER-600V TO 480V -68036H5 W6H3NZMT6 09US100A96 XFMR 1PH 10KVA 240/480X120/240 SIDE OF MACH EX96A TRANSFORMER-600V TO 480V -72044H5 W6H3NZMT6 09US250A96 XFMR 1PH 25KVA 240/480X120/240 SIDE OF MACH EX96B TRANSFORMER-600V TO 480V -48040H7 W6H3NZMT6 09US050A96 XFMR 1PH 5KVA 240/480X120/240 SIDE OF MACH EX96B TRANSFORMER-600V TO 480V -68036H5 W6H3NZMT6 09US100A96 XFMR 1PH 10KVA 240/480X120/240 SIDE OF MACH EX96B TRANSFORMER-600V TO 480V -72044H5 W6H3NZMT6 09US250A96 XFMR 1PH 25KVA 240/480X120/240 SIDE OF MACH INVD1-H BRAKING UNIT-68036H5K 380-480VOLTS W6H3NZVP 09MVBT25HC BRAKE MODULE-OPEN CHASSIS CONTROL BOX INVD1-L BRAKING UNIT-68036H5K 200-240VOLTS W6H3NZVP 09MVBT25LC BRAKEMODULE OPEN CHASIS INVERT CONTROL BOX MT >>>MOTORS MTD MOTOR-DRIVE W6H3NZVP MESSAGE SO SEE SPECIFIC COMPONENT+NAMEPLATE MACHINE TOP MTDO MOTOR-HYDRAULIC PUMP W6H3NZHD MESSAGE SO SEE SPECIFIC COMPONENT+NAMEPLATE MACHINE REAR
Page 4 of 8
4
