Milnor MWF C Series Schematic/Electrical Parts

W6H3NZTG3
MICRO 6 SYSTEMS
CONTROL BOX LAYOUTS
PELLERIN MILNOR CORPORATION
W6H3NZTG3
2018352B
W6H3NZTG3
2018352B
W6H3NZTG3
2018352B
MILTOUCH-EX CONTROLS
WASHER EXTRACTOR
CONTROL BOARDS INPUTS/OUTPUTS
PELLERIN MILNOR CORPORATION
TM
B2T2014013
2016345A
BIO-1
INPUTS
0 HI LEVEL REUSE TANK
1 DOOR CLOSED
2 INVERTER FAULT
3 NOT USED
4 WASH POSITION
5 LOAD POSITION
6 DON'T ALLOW CHEM
7 BASKET ROTATING
8 EXCURSION
9 NOT USED
10 BRAKE PAD WORN
11 BRAKE IS OFF
12 DOOR OPEN DESIRED
13 EXTRACT SPEED LIMIT
14 NOT USED
15 3-WIRE ON
OUTPUTS
0 RECIRCULATE PUMP
1 COOLDOWN
2 CHEMICAL FLUSH
3 CHEMICAL #4
4 CHEMICAL #1
5 CHEMICAL #3
6 CHEMICAL #2
7 CHEMICAL #5
BIO-2
INPUTS
16 NOT USED
17 NOT USED
18 NOT USED
19 NOT USED
20 NOT USED
21 BEARING SEAL DEFLATED
22 NOT USED
23 EXTERNAL FAULT
24 NOT USED
25 OK TO STEAM TANK
26 RECIRCULATION PUMP O/L
27 TANK PUMP O/L
28 SIGNAL CANCEL
29 FRESH METER
30 SEWER METER
31 TANK METER
OUTPUTS
32 FRESH WATER TO MACH
33 TANK TO SEWER
34 FRESH TO TANK
35 FLOW STOP
36 DOOR LOCK
37 STEAM TANK
38 SPD RAMP HOLD
39 PULSE START
BO24-1
OUTPUTS
8 TANK TO MACHINE
9 ACCELERATE/DECELERATE
10 DOOR UNLOCK
11 CLOCKWISE WASH
12 COUNTER CLOCKWISE WASH
13 STEAM
14 SIGNAL
15 3-WIRE ENABLED
16 NOT USED
17 HOT WATER
18 COLD WATER
19 EXTRA WATER
20 DRAIN TO SEWER
21 DRAIN TO REUSE
22 MACHINE TO MACHINE
23 MACHINE TO TANK
24 NOT USED
25 NOT USED
26 NOT USED
27 NOT USED
28 NOT USED
29 NOT USED
30 NOT USED
31 NOT USED
BO24-2(OPTIONAL)
LIQUID SUPPLIES
OUTPUTS
40 CHEM #14
41 CHEM #9
42 CHEM #13
43 FLUSH MANIFOLD
44 CHEM #15
45 CHEM #11
46 CHEM SAVE
47 DR UNLOCK (PULSE)/BASE BLK
48 CHEM #10
49 DOORLOCK PULSE(30022)
50 CHEM #6
51 CHEM #7
52 CHEM #8
53 CHEM #12
54 AUTO RECIRCULATION
55 NOT USED
56 NOT USED
57 NOT USED
58 DRAIN SAVER
59 MOVE TO LOAD POSITION
60 NOT USED
61 MOVING
62 NOT USED
63 MOVE TO WASH POSITION
BO24-3(OPTIONAL)
20 PROGRAMMABLE
OUTPUTS
OUTPUTS
64 OUTPUT 0
65 OUTPUT 1
66 OUTPUT 2
67 OUTPUT 3
68 OUTPUT 4
69 OUTPUT 5
70 OUTPUT 6
71 OUTPUT 7
72 OUTPUT 8
73 OUTPUT 9
74 OUTPUT 10
75 OUTPUT 11
76 OUTPUT 12
77 OUTPUT 13
78 OUTPUT 14
79 OUTPUT 15
80 OUTPUT 16
81 OUTPUT 17
82 OUTPUT 18
83 OUTPUT 19
84 NOT USED
85 NOT USED
86 NOT USED
87 NOT USED
PELLERIN MILNOR CORPORATION
B2T2015003
2017146A
48040M7, 68036M5, 72046M5
SPBS
SPD
SPBP
VEWVH
N/C
VETCW
N/C
VEWVX
N/C
VEPPO
N/O
VEWVC
N/C
VEDL
N/C
VEHDL
N/C
VEDRS
N/C
VEBR
N/C
VESTM
N/C
WCV
VEDRR
N/O
