Milnor MWF C Series Schematic/Electrical Parts

1
2
3
8
Wire identification marking.
This designation is
stamped on the wire every
6 inches and is used with
the signal routing table.
Page line
numbers
Major revision
(letter)
Page number
(S+)
Machine type
(Gas fired dryer)
6th generation
of controls
W = Wiring
Class of control system
Title of this circuit
Voltage of this circuit
4
This indicates on which
page (W6DRYGS+) and
line number (08) the relay
coil can be found for this
set of contacts
BMP010012 (right) / 2018343
25
