J
4
1
G
FE
C
H
B
B
3
2
5
6
6
BMP130080/2018195A
MWF45J8, MWF45Z8, MWF63J7, MWF63Z7, MWF77J7, MWF77Z7
MWF63C7, MWF63Y7, MWF77C7, MWF77Y7
PELLERIN MILNOR CORPORATION
Figure 1: Peristaltic Diagram
Peristaltic Supply
AA. Cross section
C. Cold water line
E. Hot water line
F. Hot water to flush the chemical supplies
G. Water and chemical supplies to the shell
H. Hot and cold water to the shell
J. Apply adhesive to the surfaces that connect. Then, tighten the clamp.
View A-A
Page (1 / 2)
84
