Pre-Assembly
PLANNING INSTALLATION
Remove the Hardware from the Hardware Sack and verify that all the Hardware shown are included.
TOOLS REQUIRED
Safety
goggles
(1) 9/16 in.
Wrenches
(1) 1/2 in.
Wrenches
(1) Flat Head
Screwdriver
(1) Hammer
(1)
Pliers
HARDWARE INCLUDED
NOTE: Hardware not shown to actual size.
Part
Description
Quantity
A
1/8 in. x 1-1/4 in. Cotter Pin
2
B
3/4 in. Flat Washer
4
C
3/8 in. Hex Head Jam Nut
8
D
3/8 in. Lock Washer
8
E
5/16 in. Hex Head Nut
4
F
5/16 in. Lock Washer
4
G
3/8 in. x 3/4 in. Truss Head Bolt
8
H
1” Square Tube Plug
2
I
5/16 in. x 3/4 in. Truss Head Bolt
4
J
1 in. x 1 in. Spacer
2
___A
___B
___C
___D
___E
___I
___H
___G
___F
___J
