Service Parts (continued)
750 LB STEEL DUMP CART
Ref #
Part #
Description
Qty
Ref #
Part #
Description
Qty
1
4568C
Wheel
2
14
1645
1/4 in. x 3-1/2 in. Hex
Head Bolt
1
2
5033TB
Cart Body
1
15
4899-1
1 in. x 1 in. Spacer
2
3
4560
Tailgate
1
16
1262
1/8 in. x 1-1/4 in. Cotter
Pin
2
4
1252
Axle
1
17
1264
3/4 in. Flat Washer
4
5
4631P
Tow Bar
1
18
1273
3/8 in. Hex Head Jam Nut
8
6
1243VNW
Clevis
1
19
1274
3/8 in. Lock Washer
8
7
1265VNW
Foot Latch
1
20
4708TB
Under Carriage
4
8
4468
1/4 in. x 2-3/4 in. Spacer
1
21
4630TB
Pedestal
4
9
4497
Spring
1
22
4552
3/8 in. x 3/4 in. Truss Head
Bolt
8
10
1558
1/4 in. Nylock Nut
1
23
2176
1” Square Tube Plug
2
11
1586
5/16 in. x 3/4 in. Truss
Head Bolt
6
12
1275
5/16 in. Hex Head Nut
6
13
1276
5/16 in. Lock Washer
6
**Not all washers may be used.
Troubleshooting
Maintenance
□ Empty the Cart after each use. Do not store the Cart with material left in the Cart.
□ Wash the Cart thoroughly and wipe dry.
□ Lubricate all moving parts.
Storage
□ Rinse the inside of the body and the exterior of the Cart.
□ Store in a clean, dry area.
Issue
Cause
Solution
The Tailgate does not close.
The Tailgate is jammed.
Check for obstructions or damage to the
Tailgate.
The Wheels skid when operating.
The Wheels are jammed.
Check for obstructions or damage to the Wheels.
