OPERATION
WARNING
To reduce the risk of injury, always
wear safety goggles or glasses
with side shields.
Selecting Hammer, Drill or Drive Action
(Cat. No. M18 ONEPD2)
1. To use the hammer-drilling
mode, rotate the torque selector
collar until the hammer symbol
appears in line with the ar-
row. Apply pressure to the bit to
engage the hammering mecha-
nism.
NOTE: When using carbide bits, do not use water
to settle dust. Do not attempt to drill through steel
reinforcing rods. This will damage the carbide bits.
2. To use the drilling only mode,
rotate the torque selector collar
until the drill symbol
appears
in line with the arrow.
NOTE: The number selected on
the torque selector collar has no
3. To use the driving screws
mode rotate the torque selector
collar until the desired clutch set-
ting appears in line with the ar-
row.
The adjustable clutch, when
properly adjusted, will slip at a preset torque to
materials and to prevent damage to the screw or
tool.
-
mate values obtained with a fully charged battery
pack.
TORQUE SPECIFICATIONS
Clutch
Setting
Nm Applications
1-4
5-8
9-11
12-14
2.8-4.5
5.0-6.8
7.3-8.5
9.0-10.2
Small screws in softwood.
Medium screws in softwood
or small screws in hardwood.
NOTE: Because the settings shown in the table are
only a guide, use a piece of scrap material to test
into the workpiece.
Mode Selector
Selector
button
Kickback
Control
Indicator
Modes
1, 2, 3
ONE-KEY™
Indicator
Allow the tool to come to a complete stop before
changing modes. Press the selector button
to
cycle between the settings. When the tool is con-
nected to the ONE-KEY App™, the indicator will
blink blue. Select wireless
to change the default
RPM, BPM, and kickback control settings via the
ONE-KEY™ App on your smart device. All modes
default to maximum speeds until changed via the
ONE-KEY™ App.
When Kickback Control is on, the
light will be
solid green. If the tool detects a sudden twisting mo-
light will blink
green.
Selecting Speed
The speed selector is on top of the motor housing.
Allow the tool to come to a complete stop before
changing speeds. See “Applications” for recom-
mended speeds under various conditions.
1. For Low speed, push the speed selector to display
“1”.
2. For High speed, push the speed selector to display
“2”.
Using the Control Switch
The control switch may be set to three positions:
forward, reverse and lock. Due to a lockout mecha-
nism, the control switch can only be adjusted when
the ON/OFF switch is not pressed. Always allow the
motor to come to a complete stop before using the
control switch.
LOCK
Push to CENTRE
Reverse
Forward
For forward (clockwise) rotation, push in the control
switch from the right side of the tool. Check the
direction of rotation before use.
For reverse (counterclockwise) rotation, push in the
control switch from the left side of the tool. Check
direction of rotation before use.
To lock the trigger, push the control switch to the
centre position. The trigger will not work while the
control switch is in the centre locked position. Always
lock the trigger or remove the battery pack before
performing maintenance, changing accessories,
storing the tool and any time the tool is not in use.
