B11 User Guide
Mimosa Networks Help Site Dashboard
Copyright © 2015 Mimosa Page 7
pointed based exchange of coordinates. The green arrow and blue shaded region on the dial indicator represent
current and target signal levels, respectively. Note that the dial indicator does not represent azimuth. Azimuth may
need to be adjusted in either direction to meet the target.
B5/B5c Signal Meter
B5-Lite Signal Meter
B11 Signal Meter

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mimosa B11 and is the answer not in the manual?

Mimosa B11 Specifications

General IconGeneral
Channel Widths20/40/80 MHz
Ingress ProtectionIP67
Antenna ConnectorIntegrated
Operating Temperature-30°C to 55°C
Power MethodPassive PoE
MIMO2x2
Ethernet Ports1 x 10/100/1000 Mbps
Power SupplyPassive PoE
