Running a Traceroute Test
A network utility used to display the path and transit delay between the local device and a given destination across
an IP network.
Destination Host - The destination IP address for traceroute to send packets.
●
Resolve IP Address - Indicate whether the system should resolve and print the host name of the destination.
●
Max Number of Hops - Choose the maximum number of intermediate devices (e.g. routers) through which
●
packets must pass between source and destination.

Mimosa B11 Specifications

General

Channel Widths	20/40/80 MHz
Ingress Protection	IP67
Antenna Connector	Integrated
Operating Temperature	-30°C to 55°C
Power Method	Passive PoE
MIMO	2x2
Ethernet Ports	1 x 10/100/1000 Mbps
Power Supply	Passive PoE
