Over view of DS202
Chapter 1
Specifications
3
Functional parameters
Autonomous channel reveal
A,-B， A+B， A-B， RecA，RecB，RecC operation waveform
Mode
Contain Auto， Normal，Single，None，Scan synchronous mode
Trigger mode
ascend/descend Edge trigger mode
Setting modes available
set adaptive level, vertical range, trigger threshold mode
Waveform Functions Auto measurement
frequency/cycle time /duty cycle, voltage peak-to-peak value/
effective value /maximum value /minimum value/average value
Signal Generator
10Hz~1MHz square wave (duty adjustable) or 10Hz~20KHz Sine/
Square/Triangle/Sawtooth wave
Product parameters
Memory capacity
Installed USB flash disk memory capacity 8MB， available for waveform
statistics and pictures
Battery
built-in 550mAhlithium battery, external USB port
Display
Color TFT LCD display (resolution320×240)
Touch key-press
Capacitive touch key-press input, support swipe gestures input
Dimension
Dimension（100mm×56.5mm×10.7mm）
