Min DS202 - Specifications

Performance parameters
Analog bandwidth
1MHz
Maximum sampling rate
10MSa/s
Maximum sample memory depth
8K
Analog input impedance
1MΩ
Maximum input voltage
±40V(X1 probe)
Coupling
AC/DC
Vertical Sensitivity
20mv/Div~10V/Div (in 1-2-5 sequence step)
Horizontal time base speed
1uS/Div~2S/Div(in 1-2-5 sequence step)
Over view of DS202
Chapter 1
Specifications
