Wiring
Installation
• Use 18-24 AWG wire for speed adjust potentiometer wiring. Use
14–16 AWG wire for AC line (L1, L2) and motor (A1 and A2)
wiring.
Warning
Do not install, remove, or rewire this equipment with power
applied. Failure to heed this warning may result in fire, explo-
sion, or serious injury.
This drive is isolated from earth ground. Circuit potentials are
at 115 or 230 VAC above ground. To prevent the risk of injury
or fatality, avoid direct contact with the printed circuit board or
with circuit elements.
Do not disconnect any of the motor leads from the drive
unless power is removed or the drive is disabled. Opening
any one motor lead may destroy the drive.
