Minarik PCM23001A User Manual

AC Max. Armature Armature
Line Current Voltage Horsepower
Model Voltage (Amps DC) Range Range
PCM23001A
115 10 0 – 90 1/8 – 1
230 10 0 – 180 1/4 – 2
PCM23401A
115 10 0 – 90 1/8 – 1
230 10 0 – 180 1/4 – 2
PCM23411A
115 1.5 0 – 90 1/20 – 1/8
230 1.5 0 – 180 1/10 – 1/4
Form Factor 1.37 at base speed
Acceleration Time 1 second
Deceleration Time 1 second
Load Regulation (at base speed) 2%
Input voltage signal range (input circuit is isolated; S1 to S2) 0-10 VDC
Field Voltage
115 VAC Input 50/100VDC
230 VAC Input 100/200 VDC
Field Current, Maximum 1.0 ADC
Vibration 0.5g max (0 – 50 Hz)
0.1g max (above 50 Hz)
Ambient Temp. Range (PCM23401/PCM23411) 10°C – 40°C
Ambient Temp. Range (PCM23001) 10°C – 55°C
Specifications
1

Minarik PCM23001A Specifications

General

Brand	Minarik
Model	PCM23001A
Category	Controller
Language	English
