Mindray DPM 6 - History; Tabular Trends

P/N: 046-003757-00 Rev A
Quick Reference Guide
15
 • C.O. Screen (Optional): Split screen with C.O. measurement window
on the upper portion of the main display with real time waveforms and
numeric parameters on the main display
 • Respiratory Loops Screen (Optional): Split screen with Respiratory loop
menu on the left side besides with real time waveforms and numeric
parameters on the main display
Note: The first waveform is always an ECG lead and HR is always located in the
first digital tile in the Normal Screen selection.
Panorama® Central Station Interface: Digital and waveform display selections
on the Panorama® Central Station, WorkStation, and ViewStation are
independent of the DPM 6 or DPM 7 bedside monitor.
HISTORY
Tabular Trends
To display Tabular trends on a patient on the DPM 6 or DPM 7 bedside monitor:
a. Select Review menu
(quick key) or from Main Menu (quick
key)
b. Select Tabular Trends tab
c. Select Trend Group and specify trend category or select Custom for user
defined parameters to be displayed
d. Select Interval to specify the time interval tabular trends are to be
displayed
e. Select Main Menu
(quick key) or to return to the main display
Panorama® Central Station interface: The trend display interval on the
DPM 6 or DPM 7 bedside monitor and the Panorama® Central Station are
independent. To record Tabular (List) trends on a patient on the DPM 6 or DPM
7 monitor to the integral recorder:
a. Select Review menu
(quick key) or from Main Menu (quick
key)
b. Select Tabular Trends tab
c. Select Record and confirm specified time period
