Main Unit
Front housing assembly Rear housing assembly
Front oanel
Touchscreen
Waterproof strip
Display
Screen gasket
LCD bracket
Main control board
Touchscreen control
board
Alarm lamp shade
Alarm lamp
waterproof strip
Alarm lamp board
Function key
Function key board
ON/OFF key
ON/OFF key board
Encoder
Knob
Rear panel assembly
Handle waterproof
pad
Battery door assembly
Handle bracket
Parameter connector
assembly
Parameter module
assembly
Battery compartment
assembly
Handle
Rear panel
Wifi antenna
Grounding washer
Others
Power board assembly
Battery spring
Battery interface
board assembly
Battery buckle
Main bracket
CO2 assembly
Multi-parameter board
C.O. board
SpO2 board
Parameter board
bracket
CO2 interface
assembly
NIBP gas nozzle
C.O. signal cable
Multi-parameter signal
cable
Parameter connector
Earth bracket
Recorder bracket
Interface board
waterproof pad
Interface board
Recorder
Buffer washer
Speaker
Speaker pressure plate
and spacer
Speaker spacer
Hook bracket
Rubber feet
Grounding terminal
Grounding pad
AC inlet
Power board insulator
3-way connector
Electromagnetic valve
Airway tube 2
Airway tube 1
Pump
Filter
L-shape connector
Pump cushion
NIBP pipe
Straight connector
Reducer
Parameter label
ECG signal cable
Others
Cables
Others
Others
Others
Interface label
Cables
Others
Others
