A-14 Passport 12/Passport 8 Operator’s Manual
A.7.7 IBP
Standards Meet standard of EN60601-2-34/IEC60601-2-34.
Technique Direct invasive measurement
IBP
Measurement range -50 to 300 mmHg
Resolution 1 mmHg
Accuracy ±2% or ±1 mmHg, whichever is greater (without sensor)
Refreshing rate 1 s
PPV
Measurement range 0% to 50%
Pressure transducer
Excitement voltage 5 VDC, ±2%
Sensitivity 5 V/V/mmHg
Impedance range 300 to 3000Ω
Alarm limit Range (mmHg) Step (mmHg)
Sys High
(low limit + 2) to 300
1
Mean High
Dia High
Sys Low
-50 to (high limit – 2) Mean Low
Dia Low
A.7.8 C.O.
Measurement method Thermodilution method
Measurement range
C.O.: 0.1 to 20 L/min
TB: 23 to 43 °C
TI: 0 to 27 °C
Resolution
C.O.:
TB, TI:
0.1 L/min
0.1 °C
Accuracy
C.O.:
TB, TI:
±5% or ±0.1 L /min, whichever is greater
±0.1 °C (without sensor)
Repeatability C.O.: ±2% or ±0.1 L/min, whichever is greater
Alarm range TB: 23 to 43 °C
Alarm limit Range Step
TB High (low limit + 1) to 43°C
0.1 °C
TB Low 23 to (high limit - 1) °C
