88
(3) When operation of [Set value or more] is selected [ON delay] is selected for hysteresis direction, with
S1.
(4) When operation of [Set value or less] is selected and [OFF delay] is selected for hysteresis direction
with S1.
Dis
p
la
y
Time→
S1 output ON
S1 output OFF
Hysteresis time witdh
Hysteresis data width
S1 setting value
Display
Time→
S1 output ON
S1 output OFF
Hysteresis time width
Hysteresis data width
S1 setting value
