12-9. Confirmation of analog output (When the analog output is applied.)
By pressing the key from
display, is displayed, and the analog
output of DC4 mA(DC0 V) is made. At this time, when
the under mentioned key is operated, the analog
output of DC 12 mA (DC5 V) is output in
display, and the analog output of DC
DC20 mA (DC10 V) is output in
display.
: Changeover each analog output.
: Finish the check mode.
When the analog output is not installed, the confirmation of analog output is not executed.
