・ Only during the measurement mode, the output of serial data is done.
・ The output of the data of S-I/F stops when the maximum display is set to six digits. Set the maximum
display within five digits when you use S-I/F.
・ The output of the data of S-I/F stops when decimal point is from digits. Set the decimal point less
than three digits when you use S-I/F
・ Make connection by referring to the 2-4.
13-3. Format data explanation
(1) Automatic print bit (FUN1: bit 0)
This bit can be used as a trigger at the instrument of serial interface receiving side.
(2) Display bit (ST1:bit 7､bit 6)
Bit 7: When the display of the instrument is gross weight, set as [1].
Bit 6: When the display of the instrument is net weight, set as [1].
13-4. Explanation of output type
(1) Stream mode
Keep outputting the data of gross weight and the net weight in constant intervals.
(2) Print signal operation
Print signal operation is selected by function F-37 and can be selected from [OFF], [Synchronizing
with print signal], [Synchronizing with accumulation signal], and [Synchronizing with finish signal].
When [Synchronizing with print signal] is selected, send with [1] set to the automatic print bit on the
FUN1 of output format synchronized with the key, the external control input, or automatic
printing.
When [Synchronizing with accumulation signal] is selected, send with [1] set to the automatic print bit
on the FUN1 of output format when [Accumulation command] is input by the function F-50 setting,
key, or external control input.
When [Synchronizing with finish signal] is selected, send with [1] set to the automatic print bit on the
FUN1 of output format when [Forced batch finish] is input by the key or external control input or
synchronized with the batch finish signal.
Default is set to [OFF].
The automatic print bit is usually 0.
