112
(5) Synchronizing with finish signal
Data is output when [Forced batch finish] is input by F key or external control input or synchronized
with the batch finish signal.
RS-485 interface keeps outputting data at the fixed space when the stream mode is selected.
Moreover, the control becomes impossible for the host.
14-3-2. Specifications of communication by RS-485
The specification of the communication by RS-485 is selected by function F-42.
Function No. Set value Contents
F-42 00000
～13121
0 0 0 0 0
Data bit length
0：7 bit or 1：8 bit
Parity bit
0：No parity
1：Even parity
2：Odd parity
Stop bit
0：1 bit or 1：2 bit
Baud rate 0 : 1 200 bps, 1 : 2 400 bps
2 : 4 800 bps, 3 : 9 600 bps
4 : 19 200 bps, 5 : 38 400 bps
Terminator
0 : CR or 1 : CR＋LF
Default is set to [13020].
14-3-3. Address setting of RS-485
The address setting of RS-422/485 is set by the setting of function F-43.
Setting range: 00 ~ 31
Default is set to [00].
14-3-4. Delay time of RS-485 return data
When the transmitting terminal on the host side enters the state of low impedance after the host side
transmission ends, the return data of the CSD-903 side can be delayed.
The delay time of RS-485 return data is set by the function F-45.
Setting range: 00 ~ 99, Unit: 10 ms
Default is set to [01].
14-3-5. Transmission data decimal point existence of RS-485
The transmission data decimal point existence of RS-485 is selected by function F-46.
Default is set to [No decimal point].
14-3-6. Output target at the stream mode in RS-485 interface
Output target is selected by the setting of function F-48.
Output target is selectable from [Display interlock], [Gross value], [Net value] or [Conditional load
display data].
Default is set to [Display interlock].
Function F-48 becomes effective when function F-47 is set to [2].
