(11) Finish calibration
The calibration data such as zero point and the span point that is registered temporary are stored in
holding register address 56848 and returned to the measurement mode.
[1] is written in holding register address 56848.
[1] is automatically rewritten as [0] after writing is normally completed.
Error outside the setting range
When the data outside the setting range is written, the following code is set.
Condition Error code Contents
illegal data 0x03 When data outside [1] is written.
(12) Calibration forced finish.
When [0] is written in holding register address 56833 during the calibration procedure, the calibration
is discontinued without storing the calibration data that is registered temporary, and you can return to
the measurement mode.
15-1-2. Fine adjustment mode for Zero and Span
Each item of the flow chart corresponds to each procedure of [4-4. Details of procedure for
fine adjustment of Zero point and Span point].
Please refer [4-4. Details of procedure for fi ne adjustment of Zero point and Span point] for
the details.
・ While executing the calibration by transmission, (–RS–) is displayed.
・ When the calibration is compulsorily finished, all the data returns to the condition before the
calibration without executing the registration.
・ Please register the data for the calibration with the weight after confirming the stable condition
without fail.
(1) Change to the fi ne adjustment mode for Zero
point and Span point
(2) Zero stability check
(3) Fine adjustment of zero point.
(4) Span stability check
(5) Fine adjustment of span point
(6) Finish of fine adjustment of zero point and span
point
To Next Page
