15-1-3. Calibration mode of digital linearization
Each item of the flow chart corresponds to each procedure of [4-5. Details of procedure for fine
adjustment of Zero point and Span point].
Please refer [4-5. Details of procedure for fi ne adjustment of Zero point and Span point] for the details.
・ While executing the calibration by transmission, (–RS–) is displayed.
・ When the calibration is compulsorily finished, all the data returns to the condition before the
calibration without executing the registration.
・ Please register the data for the calibration with the weight after confirming the stable condition
without fail.
(1) Change to digital linearization mode
Shift to digital linearization mode by writing [11] in holding register address 56833.
(2) Stability check at point No. 1
Weights are placed for the point to be calibrated on the weighing section and Stable/Unstable is read
out from holding register address 56845.
0 : Unstable 1 : Stable
(1) Change to digital linearization mode
(2) Stability check at point No.1
(3) Compensation at point No.1
(4) Stability check at point No.2
(5) Compensation at point No.2
(6) Stability check at point No.3
(7) Compensation at point No.3
(8) Finish the digital linearization mode
