4) Input of setting for the fifth decimal point digit
2 4 6 8 10 12 14 16
@ 0 0 9 0 1 2
Terminator
At normal operation
Return (CSD-903 → Host)
2 4 6 8 10 12 14 16
@ 0 0 9 0 1 2
Terminator
This is the input of the fifth decimal point digit.
(ex) Input data = 100001 ⇒1.00001mV/V
At abnormal operation
Return (CSD-903 → Host)
2 4 6 8
@ 0 0 E R 2 2
Terminator
2 4 6 8
@ 0 0 E R 2 3
Terminator
・ The command that registers mV/V of five digits below the decimal point for ZERO (No.09) and SPAN
(No.12) aiming at the performance gain of the calibration is added since ROM Ver. 2.300.
When you use the command that newly registers mV/V of ZERO and SPAN, please use the command
that registers mV/V of five digits below the decimal point for ZERO (No.9) and SPAN (No.12)
・ When this instrument is built into the system that has already used mV/V of four digits below the
decimal point for ZERO (No.08) and SPAN (No.11), you can use the command as it is.
Please note the mistake of the set digit number when changing to the command of five digits below
the decimal point by registering mV/V of ZERO (No.9) and SPAN (No.12).
A
ddress
00 to 31
A
ddress
00 to 31
A
ddress
00 to 31
Command No.
Numbe
r
Setting value
Sign
A
ddress
00 to 31
Command No.
Numbe
r
Setting value
Sign
