(1) Remove the connecting cable for strain gage applied transducer from the terminal.
(2) Measure the voltage between A-C after short-circuiting A-F and C-G of terminal board.
* Set the connecting range to DC-V for the measuring instrument such as tester and so on.
The voltage between
A and C is stable in the set value of
excitation voltage.
(1) Shorten the B, D and C in the connector.
(2) Confirm the output voltage of the load cell according to the paragraph 12-6.
The display stabilizes
with the optional value
(1) Please confirm the wiring status according to the contents of paragraph 2.
(2) Please confirm whether there may have the influence from the noise
source such as inverters.
Same condition
Start measurement
No
No
No
Inform us about the contents of failure
and situation at site in details.
Inform us about the contents of
failure and situation at site in details.
Yes
Yes
Yes
To Next Page
