Setting table of Sub-display panel (F-19)
Set value Contents Set value Contents
0 OFF 11 K Brand (1 digit) / S1 (6 digits) / S3
(6 digits)
1 A Brand (1 digit) / Accumulation times
(6 digits) / Accumulation value (8
digits)
12 L Brand (1 digit) / S1 (6 digits) / S4
(6 digits)
2 B Brand (1 digit) / Accumulation times
(6 digits) / Last accumulated data
(6 digits)
13 M Brand (1 digit) / S2 (6 digits) / S3
(6 digits)
3 C Brand (1 digit) / Last accumulated
data (6 digits) / Accumulation value
(8 digits)
14 N Brand (1 digit) / S2 (6 digits) / S4
(6 digits)
4 D Brand (1 digit) / Last accumulated
data (6 digits) / OK (6 digits)
15 O Brand (1 digit) / S3 (6 digits) / S4
(6 digits)
5 E Brand (1 digit) / Accumulation times
(6 digits) / OK (6 digits)
16 P Brand (1 digit) / OK (6 digits)
6 F Brand (1 digit) / OK (6 digits) /
Accumulation value (8 digits)
17 Q Brand (1 digit) / Over (5 digits) /
Under (5 digits)
7 G Brand (1 digit) / Near zero (6 digits)
/ Full (6 digits)
18 R Brand (1 digit) / Accumulation
times (6 digits)
8 OK (6 digits) / Over (5 digits) /
Under (5 digits)
19 S Brand (1 digit) / Accumulation
value (10 digits)
9 I Brand (1 digit) / OK (6 digits) / Free
fall (6 digits)
20 T Brand (1 digit) / Last
accumulated data (6 digits)
10 J Brand (1 digit) / S1 (6 digits) / S2 (6
digits)
