9-4-3. Supplementary Batch (discharge) mode
Supplementary batch (discharge) is a function to make the Dribble batch ON automatically in fixed
time, when the batch (discharge) weight becomes short in the Sequential batch (discharge) mode.
In order to execute supplementary batch (discharge), set the items of [Maximum times of
supplementary flow], [Time of supplementary batch] and [Waiting time after supplementary batch] after
referring to [9-9. Function of the SQ function data].
Judgment condition
Status display Judgment condition
Z-BAND
|Gross weight or (Net weight) |≦ Set value of near zero(SET7).
F. F LOW
Net weight ≧ [Final (SET1) – Prelim 2 (SET4) ]
M. FLOW
Net weight ≧ [Final (SET1) – Prelim 1 (SET3) ]
D. FLOW
Net weight ≧ [Final (SET1) – Free Fall (SET2) ]
UNDER
Net weight ＜ [Final (SET1) – Under (SET6)]
OVER
Net weight ＞ [Final (SET1) + Over (SET5)]
OK
[Final (SET1) – Under (SET6) ≦ Net weight ≦ Final (SET1) + Over (SET5) ]
Operating explanation
1) When the start signal is input, the Full flow, Medium flow and Dribble flow will be ON.
Moreover, tare weight cancellation is provided with the input of start signal with the setting at the
same time.
2) When the net weight is the value of [Final value – Prelim 2], the output of Full flow becomes OFF.
3) When the net weight is the value of [Final value – Prelim 1], the output of Medium flow becomes
OFF.
4) When the net weight is the value of [Final – Free Fall], the output of Dribble flow becomes OFF.
5) After completing the Dribble flow, the supplementary flow starts when the [Under] signal is output in
stable time. The time of this supplementary flow will become the set time in SQ function (SQF-35).
6) The supplementary flow can be made with the set times of maximum times of supplementary flow
described in the (8-9-2. The item of Sequence control setting). When the Under signal can’t be
output at less times than the set value, then the supplementary flow shall be finished at the time.
7) The Under signal is output even if the supplementary flow is applied with the same times of the
maximum supplementary flow, it will become the sequence error (SQ ERR2)
● The comparative target of near zero can be selected from Gross weight and Net weight.
● The near zero will become simple comparison operation.
● The Full flow, Medium flow and Dribble flow will never become ON until the next start signal will be
input, once it becomes OFF.
● Under, Over and OK can be operated with Net weight.
The comparison operation can be changed to simple comparison.
● At the time of setting [Prelim 2=0], the Free flow becomes OFF and at the time of setting [Prelim
1=0], Medium flow becomes OFF.
● When making the automatic tare cancellation at the time of flow start, set to [Effective] for
[Automatic tare cancellation at the time of flow start] after referring to [9-9. Function of the SQ
function data].
Renewing the output of each condition display is synchronizing with A/D sampling.
